1.产 品 资 料 介 绍：
- 原装 NI PCI-6561，采用标准 PCI 总线接口。
- 支持 LVDS 差分信号，抗干扰能力突出。
- 配备多路独立通道，可同时处理多组信号。
- 运行时钟频率高，数据传输速度快。
- 搭载大容量板载存储，可缓存大量测试数据。
- 时序控制精准，信号抖动小。
- 支持多种触发模式，适配不同测试需求。
- 具备多设备同步功能，组网测试更稳定。
- 接口规格标准，接线对接简单方便。
- 工作温度范围适中，适配机房及产线环境。
- 兼容多款主流测试软件，二次开发便捷。
- 集成信号收发功能，兼具发生与分析能力。
- 电路布局优化，长期连续工作性能稳定。
- 自带状态监测，可实时查看设备运行情况。
- 体积小巧，适配常规工控机箱安装。
NI PCI-6561分析仪模块 产品英文
The NI PCI-6561 analyzer module is a dedicated board for industrial control testing, with excellent signal acquisition and analysis performance.
Original NI PCI-6561, using standard PCI bus interface.
Supports LVDS differential signaling with outstanding anti-interference ability.
Equipped with multiple independent channels, capable of processing multiple sets of signals simultaneously.
High clock frequency and fast data transmission speed.
Equipped with large capacity onboard storage, it can cache a large amount of test data.
Accurate timing control with minimal signal jitter.
Support multiple triggering modes and adapt to different testing requirements.
Equipped with multi device synchronization function, network testing is more stable.
Standard interface specifications, simple and convenient wiring docking.
The working temperature range is moderate and suitable for the environment of the computer room and production line.
Compatible with multiple mainstream testing software, convenient for secondary development.
Integrated signal transmission and reception functions, with both generation and analysis capabilities.
Optimization of circuit layout, stable long-term continuous operation performance.
Equipped with status monitoring, it can view the real-time operation status of the device.
Compact in size, suitable for installation in conventional industrial control chassis.
Overall, the NI PCI-6561 analyzer module has high transmission speed and strong compatibility, making it a reliable accessory for industrial digital signal testing.
NI PCI-6561分析仪模块 产品展示
