Atlas Copco PF3107-C-IB2-HW驱动器
1.产 品 资 料 介 绍：
一、产品概述
PF3107-C-IB2-HW 是 Atlas Copco Power Focus 3100 系列控制器中的一款，用于驱动和管理 Tensor 3 至 7 系列电动拧紧工具，支持高精度、可追溯的拧紧作业，广泛应用于自动化工业装配生产线上。
二、技术参数（简要）
产品型号：PF3107-C-IB2-HW
适配工具：Tensor 3 至 Tensor 7 电动扭矩工具
输出功率：约 300 瓦
输入电压：90–120V / 180–240V AC，50/60Hz
重量：约 10–11 公斤
结构类型：模块化设计，可配合 IB2 接口模块使用
接口特性：
支持 IB2 工业总线（常用于工厂自动化系统集成）
可连接上位机系统、PLC、I/O 单元，实现自动工艺控制
控制能力：
支持多种拧紧策略（扭矩控制、转角控制、多通道、多步序列）
可存储多达数百个程序，适应复杂工艺
三、主要应用领域
1. 汽车制造装配
发动机、底盘、转向系统等关键部位拧紧
满足高精度与工艺一致性要求
适用于柔性工位与机器人协同作业
2. 工程机械与重工业
大型零部件（如吊臂、液压系统）的结构螺栓连接
高扭矩场景下稳定性控制
支持多工具同步控制及数据记录
3. 工业设备制造
电机、泵体、压缩机等设备的紧固
高节拍生产线中需要快速切换的多程序控制器
4. 家电与电子设备装配
用于压缩机、电控单元等部位螺丝锁附
数据可追溯，支持质量统计与分析
英文资料：
1、 Product Overview
PF3107-C-IB2-HW is one of the Atlas Copco Power Focus 3100 series controllers used to drive and manage Tensor 3 to 7 series electric tightening tools. It supports high-precision and traceable tightening operations and is widely used in automated industrial assembly production lines.
2、 Technical parameters (brief)
Product model: PF3107-C-IB2-HW
Adaptation tool: Tensor 3 to Tensor 7 electric torque tool
Output power: approximately 300 watts
Input voltage: 90-120V/180-240V AC, 50/60Hz
Weight: Approximately 10-11 kilograms
Structure type: Modular design, can be used in conjunction with IB2 interface modules
Interface features:
Support IB2 industrial bus (commonly used for factory automation system integration)
Can connect to the upper computer system, PLC, and I/O units to achieve automatic process control
Control ability:
Support multiple tightening strategies (torque control, angle control, multi-channel, multi-step sequence)
Can store up to hundreds of programs and adapt to complex processes
3、 Main application areas
1. Automotive manufacturing assembly
Tighten key parts such as engine, chassis, steering system, etc
Meet the requirements of high precision and process consistency
Suitable for collaborative work between flexible workstations and robots
2. Construction Machinery and Heavy Industry
Structural bolt connections for large components such as cranes and hydraulic systems
Stability control in high torque scenarios
Support multi tool synchronization control and data recording
3. Industrial equipment manufacturing
Tightening of equipment such as motors, pump bodies, compressors, etc
Multi program controllers that require rapid switching in high cycle production lines
4. Assembly of household appliances and electronic devices
Used for screw locking attachments in compressors, electronic control units, and other parts
Data traceability, supporting quality statistics and analysis
2.产 品 展 示
