ATLAS COPCO PF300-G-HW电源对焦控制器

Atlas Copco  PF300-G-HW电源对焦控制器

1.产 品 资 料 介 绍：

一、产品概述

ATLAS COPCO PF300-G-HW 是 Power Focus 300 系列中的早期紧固控制器之一，用于控制 Atlas Copco 的直流电动扭矩工具。该控制器采用模块化设计，具备基本的扭矩/角度控制功能，适合中低复杂度的拧紧工艺场合，尤其适用于初级自动化或半自动化装配线。

二、主要功能简要

• 控制方式：支持扭矩控制、角度控制与步进程序控制

• 适配工具：支持与 Atlas Copco Tensor 系列工具（如 Tensor ST、ES 等）连接

• 通信能力：具备标准 I/O 控制接口，部分型号支持串口或现场总线模块

• 数据能力：具备基本拧紧数据记录、结果输出和错误报警功能

• 界面：按钮操作或外接控制面板，支持程序切换和状态显示

三、应用领域

1. 汽车零部件制造

• 适用于非总装工位，如座椅骨架、门板、内饰、车灯组装等工艺

• 满足小批量、模块化装配需求

• 可部署于手动工位或简单节拍线中

2. 家电与电子设备行业

• 应用于洗衣机、电冰箱、空调压缩机等螺栓紧固过程

• 支持对电气控制箱、电机壳体、接线端子的标准化拧紧作业

3. 轻工业装配线

• 用于小型工业设备、仪器仪表装配中的精度控制

• 支持多通道作业模式下的单一通道控制（适用于工装夹具控制系统）

4. 工具测试与维修工位

• 可作为测试平台用于新工具调试或售后维修评估

• 支持加载指定程序，模拟实际拧紧场景

5. 工程技术开发实验室

• 工艺开发过程中用于参数设定与拧紧策略验证

• 提供稳定输出与可控参数测试环境

英文资料：

1、 Product Overview

ATLAS COPCO PF300-G-HW is one of the early fastening controllers in the Power Focus 300 series, used to control Atlas Copco's DC electric torque tools. This controller adopts a modular design and has basic torque/angle control functions, suitable for low to medium complexity tightening process applications, especially for primary automation or semi-automatic assembly lines.

2、 Main functions briefly

Control mode: Supports torque control, angle control, and step program control

Adaptation tool: Supports connection with Atlas Copco Tensor series tools (such as Tensor ST, ES, etc.)

Communication capability: Equipped with standard I/O control interfaces, some models support serial or fieldbus modules

Data capability: equipped with basic tightening data recording, result output, and error alarm functions

Interface: Button operation or external control panel, supporting program switching and status display

3、 Application Fields

1. Manufacturing of automotive parts

Suitable for non assembly stations, such as seat frames, door panels, interior, headlight assembly and other processes

Meet the needs of small batch and modular assembly

Can be deployed in manual workstations or simple rhythm lines

2. Household appliances and electronic equipment industry

Applied to the bolt tightening process of washing machines, refrigerators, air conditioning compressors, etc

Support standardized tightening operations for electrical control boxes, motor housings, and wiring terminals

3. Light industry assembly line

Precision control for small industrial equipment and instrument assembly

Support single channel control in multi-channel operation mode (applicable to fixture control systems)

4. Tool testing and maintenance station

Can be used as a testing platform for new tool debugging or after-sales maintenance evaluation

Support loading specified programs to simulate actual tightening scenarios

5. Engineering Technology Development Laboratory

Used for parameter setting and tightening strategy verification in the process of process development

Provide a stable output and controllable parameter testing environment

2.产      品      展      示
