Atlas Copco TC52S-N伺服驱动器
1.产 品 资 料 介 绍：
一、产品概述
ATLAS COPCO TC52S-N 是 Power MACS 系列中的高性能伺服驱动器，专为工业级紧固系统设计。广泛应用于多轴同步拧紧任务，支持多种电动工具和控制器，满足高精度和高可靠性装配需求。
二、主要功能与技术参数
输入电压：200–480V AC，三相，50/60Hz
输入电流：额定约 5A
输出电压：0–480V AC，三相
输出电流：额定 5A，最大可达 20A
频率范围：0–1600Hz
控制方式：闭环扭矩控制、角度控制、速度控制
通信接口：支持 CAN 总线与 TC 控制板连接
安装方式：标准 19 英寸机架式安装
三、应用领域
汽车制造
用于发动机、底盘、车身等多轴同步拧紧，保证装配质量和效率。机械制造
适用于液压设备、电机、泵类等高扭矩部件装配。家电与电子产品
为家电、电子产品装配线提供高效精准的紧固解决方案。轨道交通与航空航天
满足高标准紧固要求，支持过程可追溯和数字化分析。
英文资料：
1、 Product Overview
ATLAS COPCO TC52S-N is a high-performance servo drive in the Power MACS series, designed specifically for industrial grade fastening systems. Widely used in multi axis synchronous tightening tasks, supporting multiple electric tools and controllers to meet high-precision and high reliability assembly requirements.
2、 Main functions and technical parameters
Input voltage: 200-480V AC, three-phase, 50/60Hz
Input current: rated at approximately 5A
Output voltage: 0-480V AC, three-phase
Output current: rated 5A, maximum up to 20A
Frequency range: 0-1600Hz
Control methods: closed-loop torque control, angle control, speed control
Communication interface: Supports connection between CAN bus and TC control board
Installation method: Standard 19 inch rack mounted installation
3、 Application Fields
automobile making
Used for synchronous tightening of multiple axles such as engines, chassis, and vehicle bodies to ensure assembly quality and efficiency.
Machinery manufacturing
Suitable for assembly of high torque components such as hydraulic equipment, motors, pumps, etc.
Home appliances and electronic products
Provide efficient and precise fastening solutions for home appliance and electronic product assembly lines.
Rail Transit and Aerospace
Meet high standard fastening requirements, support process traceability and digital analysis.
2.产 品 展 示
