ATLAS COPCO 2102-S4-115R传感器

Atlas Copco  2102-S4-115R传感器

1.产 品 资 料 介 绍：

一、产品概述

ATLAS COPCO 2102-S4-115R 是一款集成在 Power Focus 控制器系统中的扭矩/角度传感器组件，通常用于配合 Tensor S4 系列电动拧紧工具进行工业级精密装配作业。

此型号多见于 Power Focus 2100 系列控制器，用于中低复杂度的拧紧应用，是 Atlas Copco 工业紧固系统中的重要组成部件。

二、功能特性

• 扭矩与角度检测：实时捕捉并反馈扭矩、角度数据，支持闭环控制。

• 高兼容性：与 Tensor S4 系列工具高度适配，适用于多种工位。

• 控制精度高：配合控制器，实现稳定一致的紧固过程。

• 适用于 AC 115V 电源系统（115R 代表 115V 版本）。

三、主要参数（典型配置）

• 型号：2102-S4-115R

• 适配工具：Tensor S4 电动伺服工具

• 控制器平台：Power Focus 2101 或 Power Focus 2100 系列

• 供电要求：115V AC 单相

• 功能模块：含拧紧数据传感器、信号处理模块、基础 I/O 接口等

四、应用领域

1. 汽车行业

   • 用于座椅、门锁、内饰、悬挂小零件等中低扭矩部位装配

   • 满足流程监控和可追溯要求

2. 家电与电子制造

   • 精密螺丝拧紧，如马达壳体、电控盒、面板固定等

3. 轻型机械组装

   • 通用机械、电机、泵类设备外壳或连接部位紧固任务

4. 维修与工具校准场景

   • 用于配合测试工具进行扭矩校验与数据对比

英文资料：

1、 Product Overview

ATLAS COPCO 2102-S4-115R is a torque/angle sensor component integrated into the Power Focus controller system, typically used for industrial grade precision assembly operations in conjunction with Tensor S4 series electric tightening tools.

This model is commonly found in the Power Focus 2100 series controllers and is used for low to medium complexity tightening applications. It is an important component of the Atlas Copco industrial fastening system.

2、 Functional characteristics

Torque and angle detection: Real time capture and feedback of torque and angle data, supporting closed-loop control.

High compatibility: Highly compatible with Tensor S4 series tools, suitable for multiple workstations.

High control accuracy: With the cooperation of the controller, a stable and consistent fastening process can be achieved.

Suitable for AC 115V power supply system (115R represents 115V version).

3、 Main parameters (typical configuration)

Model: 2102-S4-115R

Adaptation tool: Tensor S4 electric servo tool

Controller platform: Power Focus 2101 or Power Focus 2100 series

Power supply requirement: 115V AC single-phase

Functional modules: including tightening data sensors, signal processing modules, basic I/O interfaces, etc

4、 Application Fields

Automobile industry

Used for assembly of low and medium torque parts such as seats, door locks, interior, and suspension components

Meet the requirements of process monitoring and traceability

Home appliances and electronics manufacturing

Precision screw tightening, such as motor housing, electrical control box, panel fixing, etc

Light machinery assembly

Tightening tasks for enclosures or connection parts of general machinery, motors, and pumps

Maintenance and tool calibration scenarios

Used for torque verification and data comparison in conjunction with testing tools

2.产      品      展      示
