ATLAS COPCO TC52P-N伺服驱动器

Atlas Copco TC52P-N伺服驱动器

1.产 品 资 料 介 绍：

一、产品概述

TC52P-N 是 Atlas Copco TC5000 系列中的一款工业级 伺服驱动器控制单元，主要用于驱动和控制 Atlas Copco 的多轴伺服拧紧工具。该型号中的：

• TC52 表示所属系列（高端控制平台，支持多通道伺服控制）

• P 表示通信接口类型为 PROFIBUS

• N 通常表示 基础配置或标准单通道控制模块

该产品作为伺服拧紧系统的重要组成部分，广泛应用于对扭矩控制精度和数据可追溯性要求极高的工业场合。

二、主要功能与技术参数

• 产品类型：伺服驱动器控制单元

• 通信协议：PROFIBUS-DP（支持与西门子等主流PLC对接）

• 控制能力：

  • 扭矩、角度、速度等三维闭环控制

  • 支持多段拧紧程序（如预紧、主拧、检测）

  • 过程曲线记录与报警分析

• 兼容系统：与 Power MACS、Tightening Software、Atlas Copco 伺服工具兼容

• 输入输出：

  • 多个数字/模拟 I/O 接口

  • 与 HMI 或 MES 系统对接

• 安全与保护：

  • 具备过温、过载、短路、失步保护

  • 电源冗余接入，提升系统稳定性

• 安装方式：控制柜内模块化集成，DIN 导轨或固定板安装

英文资料：

1、 Product Overview

TC52P-N is an industrial grade servo drive control unit in the Atlas Copco TC5000 series, mainly used to drive and control Atlas Copco's multi axis servo tightening tools. In this model:

TC52 represents its series (high-end control platform, supporting multi-channel servo control)

P indicates that the communication interface type is PROFIBUS

N usually represents the basic configuration or standard single channel control module

As an important component of servo tightening systems, this product is widely used in industrial applications that require high precision in torque control and data traceability.

2、 Main functions and technical parameters

Product Type: Servo Drive Control Unit

Communication protocol: PROFIBUS-DP (supports integration with mainstream PLCs such as Siemens)

Control ability:

Three dimensional closed-loop control of torque, angle, speed, etc

Support multiple tightening programs (such as pre tightening, main tightening, and testing)

Process curve recording and alarm analysis

Compatible systems: Compatible with Power MACS, Tightening Software, Atlas Copco servo tools

Input/output:

Multiple digital/analog I/O interfaces

Integrate with HMI or MES systems

Safety and Protection:

Equipped with over temperature, overload, short circuit, and out of step protection

Redundant power supply connection enhances system stability

Installation method: Modular integration inside the control cabinet, DIN rail or fixed plate installation

2.产      品      展      示
