Gasonics A90-014-01解码器模块
1.产 品 资 料 介 绍：
产品名称：Gasonics A90-014-01 解码器模块
部件类型：数字解码模块（Digital Decoder Module）
主要功能：将来自主控系统的数字编码信号解析为可驱动显示装置、报警灯或其他执行装置的控制信号，实现信号识别与指令分发
一、设备显示与状态控制核心
该解码器模块用于将主控制器传出的多位数字信号翻译为可用于显示单元（如数码管、LED 指示灯）或报警器的单独驱动信号。
典型功能：
显示工艺步骤、倒计时或错误代码
控制设备面板指示灯、蜂鸣器等响应装置
与输入/输出模块协调工作，实现状态交互
二、数字信号处理与输出
A90-014-01 模块具备解码逻辑电路，可识别多种格式的数字输入（如二进制编码、BCD 编码），并将其转换为多个通道的控制信号。
信号处理功能：
输入信号译码
多路信号分发
控制输出电平转换
三、与系统控制板的集成配合
该模块作为中间解码环节，通常连接于主控板与显示/控制组件之间，确保信号解读准确、显示及时。
相关模块搭配：
控制主板（如 ABX-88919 系列）
显示面板 / LED 显示条
警报模块、蜂鸣器或信号灯
英文资料：
Product Name: Gasonics 885-2423 Arm Control Board
Component type: Robot Arm Controller PCB
Main function: Used to control the movement behavior of the internal transfer arm (Transfer Arm/Robot Arm) of the equipment, achieving automatic transfer of wafers between various process areas
1、 Mechanical arm drive and control
This control board serves as the core control unit, coordinating the operation of servo motors, stepper drivers, position sensors, and other components to achieve precise wafer picking, placing, and movement.
Typical control functions:
Wafer picking/placing action control
Sending commands for arm horizontal/vertical movement
Clamping device opening and closing control
Action path planning and position calibration
2、 Signal input/output interface
Establish multi-channel signal interaction between the control board, sensors, and actuators, including position feedback, action confirmation, limit protection, etc., to ensure the safety and reliability of the handling process.
Interface support:
Multi axis motor drive signal
Encoder/limit switch feedback input
Movement completion and error signal feedback
Communication interface of upper system (such as TTL, RS-232)
3、 Equipment automation system integration
The 885-2423 control board is usually integrated into Gasonics plasma equipment or other wafer processing platforms, working together with the main controller to complete material handling tasks in the process flow.
Common matching components:
Control motherboard (such as ABX-88919-41)
Stepper driver (such as RD-323M10)
Optical sensors (such as A89-004-01)
