BERGER LAHR TLC411F步进电机控制驱动器
1.产 品 资 料 介 绍：
产品名称
BERGER LAHR TLC411F 步进电机控制驱动器
一、产品概述
TLC411F 是 BERGER LAHR（现为施耐德电气旗下品牌）推出的一款通用型步进电机驱动器，设计用于精密运动控制系统。它可驱动两相或混合型步进电机，广泛用于自动化、机床控制、精密输送、半导体设备和工业检测系统等领域，提供精确的位置控制和高效的扭矩输出。
二、技术参数
输入电源：
电压：约 115 / 230 VAC（可选）
频率：50/60 Hz
输出电流：
最大相电流：可调节，一般为 1A ~ 4.5A
电流控制方式：恒流PWM调制
适用电机类型：
两相或混合式步进电机
步进控制：
支持整步、半步、微步（典型值 1/2、1/4、1/8）
步进分辨率设置灵活，可通过拨码或软件设置
接口类型：
输入：脉冲（STEP）、方向（DIR）信号接口
控制逻辑：TTL/差分信号兼容
具备报警输出、使能信号、故障诊断接口等
保护功能：
过压、过流、过热、短路保护
故障LED指示，便于故障排查
安装方式：
标准DIN导轨或螺丝安装
冷却方式：
风冷或自然对流，视安装环境而定
英文资料：
product name
BERGER LAHR TLC411F Stepper Motor Control Driver
1、 Product Overview
TLC411F is a universal stepper motor driver launched by BERGER LAHR (now a brand under Schneider Electric), designed for precision motion control systems. It can drive two-phase or hybrid stepper motors and is widely used in fields such as automation, machine tool control, precision conveying, semiconductor equipment, and industrial detection systems, providing precise position control and efficient torque output.
2、 Technical parameters
Input power supply:
Voltage: Approximately 115/230 VAC (optional)
Frequency: 50/60 Hz
Output current:
Maximum phase current: adjustable, generally ranging from 1A to 4.5A
Current control method: constant current PWM modulation
Applicable motor types:
Two phase or hybrid stepper motor
Step control:
Supports full step, half step, and micro step (typical values 1/2, 1/4, 1/8)
The step resolution setting is flexible and can be set through dialing or software
Interface type:
Input: Pulse (STEP), Direction (DIR) signal interface
Control logic: TTL/differential signal compatible
Equipped with alarm output, enable signal, fault diagnosis interface, etc
Protection function:
Overvoltage, overcurrent, overheating, short circuit protection
Fault LED indicator for easy troubleshooting
Installation method:
Standard DIN rail or screw installation
Cooling method:
Air cooling or natural convection, depending on the installation environment
