Gasonics A90-039-01电流传感器
1.产 品 资 料 介 绍：
产品名称
Gasonics A90-039-01 电流传感器
（英文：Current Sensor Module）
一、产品概述
Gasonics A90-039-01 是专为 Gasonics 系列等离子体设备设计的 电流检测模块，主要用于监测关键部件（如加热器、射频电源、电磁阀等）的电流状态。该模块将实时电流信号转换为模拟信号，传送至主控系统，实现闭环控制、状态监测和故障保护。
二、技术参数
模块类型：电流传感器 / 电流监控模块
典型应用电流范围：0–20 A（具体范围依据应用负载）
输出信号：
模拟输出（如 0–5V 或 0–10V）
或电流输出（如 4–20 mA）
检测原理：基于霍尔效应或变压器电流互感原理（视具体版本）
绝缘特性：输入与输出之间具备电气隔离
供电电压：+15V DC / +24V DC（视具体模块规格）
响应时间：快速响应，适合监控动态工艺电流
接口类型：多针端子或排线接口，连接至主控板或采集系统
安装方式：模块化插板或固定安装于设备内部电源区域
英文资料：
product name
Gasonics A90-039-01 Current Sensor
(English: Current Sensor Module)
1、 Product Overview
Gasonics A90-039-01 is a current detection module designed specifically for Gasonics series plasma equipment, mainly used to monitor the current status of key components such as heaters, RF power supplies, solenoid valves, etc. This module converts real-time current signals into analog signals and transmits them to the main control system, achieving closed-loop control, status monitoring, and fault protection.
2、 Technical parameters
Module Type: Current Sensor/Current Monitoring Module
Typical application current range: 0-20 A (specific range depends on the application load)
Output signal:
Analog output (such as 0-5V or 0-10V)
Or current output (such as 4-20 mA)
Detection principle: Based on Hall effect or transformer current mutual inductance principle (depending on the specific version)
Insulation characteristics: Electrical isolation between input and output
Supply voltage:+15V DC/+24V DC (depending on specific module specifications)
Response time: Fast response, suitable for monitoring dynamic process currents
Interface type: Multi pin terminal or ribbon cable interface, connected to the main control board or acquisition system
Installation method: Modular plug-in board or fixed installation in the internal power area of the device
2.产 品 展 示
