Gasonics A94-1168 810-2850接口模块
1.产 品 资 料 介 绍：
产品概述
Gasonics A94-1168（部件号 810-2850）接口模块是一款用于 Gasonics 等离子体设备中的通信与控制接口电路板，主要负责设备内部各子系统之间的信号连接、数据交换与状态反馈。该模块常见于 Aura 系列等离子清胶设备中，是系统逻辑控制的重要组成部分。
技术参数
型号：A94-1168
物料号：810-2850（内部识别号）
类型：多通道接口模块（I/O Interface Board）
功能：用于数字/模拟信号传输、电平转换、状态信号反馈
接口形式：多组多针连接器，适配控制主板或传感器模块
安装方式：标准插板结构，固定于设备主控框架内
适用设备：Gasonics Aura 1000、Aura 2000 等等离子清胶系统
应用场景
信号协调与接口转换
模块负责将来自主控系统的控制信号分配至各执行单元，如气阀、射频电源、真空系统等，或将反馈信号采集返回主控板。设备运行状态传输
实时传递工艺参数与各子系统运行状态，例如气压、温度、等离子体状态等。集成控制系统通信枢纽
作为控制系统的中枢接口板，用于连接上层处理器与下层电气设备之间的数据链路。
英文资料：
product overview
The Gasonics A94-1168 (part number 810-2850) interface module is a communication and control interface circuit board used in Gasonics plasma equipment, mainly responsible for signal connection, data exchange, and status feedback between various subsystems within the equipment. This module is commonly found in Aura series plasma cleaning equipment and is an important component of system logic control.
Technical Parameter
Model: A94-1168
Material Number: 810-2850 (Internal Identification Number)
Type: Multi channel Interface Board (I/O Interface Board)
Function: Used for digital/analog signal transmission, level conversion, and status signal feedback
Interface form: Multiple sets of multi pin connectors, compatible with control motherboards or sensor modules
Installation method: Standard plug-in structure, fixed inside the main control frame of the equipment
Applicable equipment: Gasonics Aura 1000, Aura 2000 and other plasma cleaning systems
Application scenarios
Signal coordination and interface conversion
The module is responsible for distributing control signals from the main control system to various execution units, such as air valves, RF power supplies, vacuum systems, etc., or collecting feedback signals and returning them to the main control board.
Equipment operation status transmission
Real time transmission of process parameters and operational status of various subsystems, such as air pressure, temperature, plasma state, etc.
Integrated Control System Communication Hub
As the central interface board of the control system, it is used to connect the data link between the upper level processor and the lower level electrical equipment.
2.产 品 展 示
