Magnetek CIMR-F7U4022矢量变频驱动器
1.产 品 资 料 介 绍：
产品概述
Magnetek CIMR-F7U4022 是一款高性能 矢量变频驱动器（Vector Inverter Drive），专为工业交流电机的精确速度和转矩控制设计。其核心控制算法支持无传感器矢量控制（Sensorless Vector Control），实现低速高转矩输出，适合多种复杂负载场合。该驱动器广泛应用于泵、风机、输送机及工业自动化设备。
技术参数
型号：CIMR-F7U4022
输入电压：三相 480 VAC ±10%
额定功率：约 22 kW（30 HP）
额定输出电流：约 38 A
输出频率范围：0.1 Hz 至 400 Hz
控制方式：
矢量控制（无传感器矢量控制）
V/f 控制
保护功能：过流、过压、欠压、过载、过热、短路保护等
通讯接口：内置 Modbus，支持选配 Profibus、DeviceNet 等工业协议
冷却方式：强制风冷
防护等级：标准 NEMA 1（可选 IP20/NEMA 12）
环境温度：工作温度范围 -10℃ 至 50℃
操作方式：面板控制或远程 PLC 控制
应用场景
泵和风机：实现节能调速及稳定控制，广泛用于 HVAC、污水处理等系统
输送设备：用于皮带输送机、提升机，实现柔性速度调节
加工机械：满足自动化生产线对转速和转矩的高精度要求
重载机械：适应起重机、破碎机等高启动转矩负载场合
英文资料：
product overview
Magnetek CIMR-F7U4022 is a high-performance Vector Inverter Drive designed specifically for precise speed and torque control of industrial AC motors. Its core control algorithm supports Sensorless Vector Control, achieving low-speed high torque output and suitable for various complex load scenarios. This driver is widely used in pumps, fans, conveyors, and industrial automation equipment.
Technical Parameter
Model: CIMR-F7U4022
Input voltage: Three phase 480 VAC ± 10%
Rated power: approximately 22 kW (30 HP)
Rated output current: approximately 38 A
Output frequency range: 0.1 Hz to 400 Hz
Control method:
Vector control (sensorless vector control)
V/f control
Protection functions: overcurrent, overvoltage, undervoltage, overload, overheating, short circuit protection, etc
Communication interface: Built in Modbus, supports optional industrial protocols such as Profibus and DeviceNet
Cooling method: forced air cooling
Protection level: Standard NEMA 1 (optional IP20/NEMA 12)
Environmental temperature: Operating temperature range -10 ℃ to 50 ℃
Operation mode: panel control or remote PLC control
Application scenarios
Pumps and fans: achieve energy-saving speed regulation and stable control, widely used in HVAC, sewage treatment and other systems
Conveyor equipment: used for belt conveyors and elevators to achieve flexible speed regulation
Processing machinery: meets the high-precision requirements of speed and torque for automated production lines
Heavy duty machinery: suitable for high starting torque loads such as cranes and crushers
2.产 品 展 示
3.其他产品
4.其他英文产品
