Magnetek GPD506V-B096驱动器
1.产 品 资 料 介 绍：
- 高功率驱动能力
- 灵活的 V/f 控制功能
- 强大的保护与诊断机制
- 多功能 I/O 接口
- 通信与扩展功能
英文资料：
1、 Product positioning and purpose
MAGNETEK GPD506V-B096 is a high-performance industrial frequency converter in the GPD506V series, mainly used for speed and torque control of large induction motors. It can adapt to heavy-duty environments and has excellent performance in automation systems that require high reliability and overload capacity.
2、 Main technical parameters
Project
Specifications
Input voltage
Three phase 380-480 VAC ± 10%
Output power
96 HP（71.5 kW）
Output frequency range
0.1–400 Hz
Control method
V/f control (programmable curve)
Overload capacity
150% rated current, lasting for 1 minute
Cooling method
Forced air cooling (with independent fan)
Protection level
Usually IP20 (shell to be confirmed)
Installation method
Embedded or wall mounted control cabinet
3、 Core features of the product
High power driving capability
It can stably drive high-power induction motors with a power of over 70kW, and can easily handle high inertia loads. It is suitable for industrial heavy-duty applications such as lifting, mixing, and compression.
Flexible V/f control function
Multiple voltage frequency characteristic curves can be set, including linear, square, and user-defined curves. It also has slip compensation and frequency hopping band setting functions to ensure stable operation of the equipment and avoid vibration.
Powerful protection and diagnostic mechanisms
There are various protection functions such as overvoltage, undervoltage, overheating, overcurrent, grounding, and instantaneous stop inside. At the same time, it has the function of displaying fault codes and recording logs, which facilitates quick maintenance and troubleshooting.
Multi functional I/O interface
Supports multiple programmable digital inputs and outputs (DI/DO), as well as analog inputs and outputs (AI/AO), which can be used for feedback control of speed and current, and can also be connected to external operation panels and remote control stations.
Communication and Expansion Functions
Communication modules such as Modbus, Profibus, and DeviceNet can be optionally selected to seamlessly integrate with PLC and HMI systems, making it easy to integrate into industrial control networks.
2.产 品 展 示
