Magnetek GPD506V-B014 变频驱动器
1.产 品 资 料 介 绍：
- 可靠的控制能力
- 多重保护功能
- 灵活的控制选择
- 丰富的接口配置
- 便捷的安装使用
英文资料：
1、 Basic Information
MAGNETEK GPD506V-B014 is a variable frequency drive in the GPD506V series, with an input of three-phase 380-480V AC voltage and a rated power of approximately 14 HP (10.4 kW). The output frequency can be adjusted between 0.1-400 Hz, and the control mode is V/f (voltage/frequency control).
2、 Main technical parameters
Project
Details
Series
GPD506V
Model number
B014
Voltage level
Three phase 380-480V AC
Rated power
About 14 HP (10.4 kW)
Output frequency
0.1 – 400 Hz
Control method
V/f (voltage/frequency control)
3、 Product advantages
Reliable control capability
Adopting stable V/f control, it can adapt to various asynchronous motors. Multiple V/f curves such as linear, square, and customizable can be set to meet the needs of different scenarios.
Multiple protection functions
Equipped with overvoltage, undervoltage, overload, overheating, and short circuit protection, it can also perform fault self diagnosis, with clear display of fault codes for easy maintenance and troubleshooting.
Flexible control options
Supports local and remote control, can be paired with operation panels such as 1995-A-6D-P-X to achieve local operation, and can also be controlled through relays, analog input/output, and remote start/stop.
Rich interface configuration
There are multiple programmable digital input/output interfaces, and analog inputs can be used for speed setting, current feedback, etc. It can also expand communication modules such as Modbus for device integration.
Convenient installation and use
Adopting a compact design and flexible installation method, it can be wall mounted or installed in control cabinets, suitable for matching small and medium-sized power equipment.
2.产 品 展 示
