Magnetek L30344电源模块
1.产 品 资 料 介 绍：
- 输入电压：采用三相交流输入，电压范围为 380V 至 460V，频率为 50/60Hz，能适应工业环境中的三相供电需求。
- 输出电压范围：3.4V DC 至 10.5V DC，且可根据实际需求进行调节，满足不同设备对直流电压的多样化要求。
- 输出功率：约 1750 瓦，具备较强的功率输出能力。
- 输出电流：最大约 500 安培（具体数值视电压设定而定），能为高功率负载提供充足的电流支持。
- 冷却方式：根据使用环境的不同，可选择自然风冷或强制风冷，确保模块在不同工况下都能保持良好的散热效果，维持稳定运行。
- 尺寸：采用标准机架安装尺寸，便于集成于控制柜或机架系统中，节省安装空间并简化安装流程。
- 高功率输出：能提供高达 1750 瓦的高功率输出，非常适合为大功率设备供电，满足设备在运行过程中的高功率需求。
- 宽输出电压范围：3.4V DC 至 10.5V DC 的可调节输出电压范围，使其能够满足不同设备的电压需求，增强了模块的通用性。
- 高电流输出能力：最大约 500 安培的输出电流，让其适用于高功率负载应用，确保负载设备能获得稳定的电流供应。
- 模块化设计：支持并联使用，通过多模块并联可以增强系统的容量，同时实现冗余性，提高系统的可靠性，即使其中一个模块出现故障，其他模块仍能继续工作。
- 多重保护机制：内置过压、过流、短路等多重保护功能，当模块出现异常情况时，能迅速做出反应，保护模块及连接的设备安全，降低设备损坏的风险。
- 广泛兼容性：兼容多种工业控制系统，应用范围十分广泛，能轻松融入不同的工业控制环境。
英文资料：
1、 Product Overview
The model is L30344 (sometimes corresponding to the label 119-8125-00), which belongs to high-power DC power supply modules. It has a wide range of applications and can be used in various scenarios such as industrial control, power systems, and communication equipment, providing stable and reliable DC power supply for devices in these fields.
2、 Main technical parameters
Input voltage: Adopting three-phase AC input, with a voltage range of 380V to 460V and a frequency of 50/60Hz, it can adapt to the three-phase power supply requirements in industrial environments.
Output voltage range: 3.4V DC to 10.5V DC, and can be adjusted according to actual needs to meet the diverse requirements of different devices for DC voltage.
Output power: about 1750 watts, with strong power output capability.
Output current: up to approximately 500 amperes (specific value depends on voltage setting), capable of providing sufficient current support for high-power loads.
Cooling method: Depending on the usage environment, natural air cooling or forced air cooling can be selected to ensure that the module can maintain good heat dissipation and stable operation under different working conditions.
Size: Adopting standard rack installation dimensions, it is easy to integrate into control cabinets or rack systems, saving installation space and simplifying the installation process.
3、 Core functions and features
High power output: It can provide up to 1750 watts of high-power output, which is very suitable for powering high-power equipment and meeting the high-power requirements of the equipment during operation.
Wide output voltage range: The adjustable output voltage range from 3.4V DC to 10.5V DC enables it to meet the voltage requirements of different devices, enhancing the versatility of the module.
High current output capability: With an output current of up to approximately 500 amperes, it is suitable for high-power load applications, ensuring stable current supply to the load equipment.
Modular design: Supports parallel use. By connecting multiple modules in parallel, the system's capacity can be enhanced, redundancy can be achieved, and system reliability can be improved. Even if one module fails, the other modules can continue to work.
Multiple protection mechanism: Built in multiple protection functions such as overvoltage, overcurrent, and short circuit. When the module encounters abnormal situations, it can quickly respond, protect the safety of the module and connected devices, and reduce the risk of equipment damage.
Wide compatibility: Compatible with various industrial control systems, with a wide range of applications, it can easily integrate into different industrial control environments.
2.产 品 展 示
