Magnetek A5-206-000 伺服放大器
1.产 品 资 料 介 绍：
- 输入电压：采用三相交流 230V AC 供电，频率为 50/60Hz，能适应相应的工业供电环境。
- 输出电流：最大约 6A，可满足相关设备伺服控制的电流需求。
- 控制方式：运用矢量控制技术，凭借该技术能够实现高精度、高速响应的控制效果，保障设备的运行精度。
- 冷却方式：可根据实际使用情况选择自然风冷或强制风冷，确保伺服放大器在工作过程中保持适宜的温度，维持稳定性能。
- 结构形式：采用模块化设计，这种设计使其适合集成于控制柜或机架中，便于安装和系统集成。
- 高性能矢量控制：借助高性能的矢量控制技术，能够提供精准的速度和位置控制，确保设备在运行过程中能够精确地按照指令完成动作，提升设备的工作精度和效率。
- 宽广的调速范围：具备宽广的调速范围，既能满足设备低速启动时的平稳性要求，又能适应高速运行时的快速响应需求，增强了设备在不同工况下的适应性。
- 多种控制接口：配备多种控制接口，支持模拟量和数字量输入，方便与不同的控制设备和系统进行连接，提高了伺服放大器的兼容性和灵活性。
- 内置多重保护功能：内置了过载、过压、过流和短路等多重保护功能，当设备出现异常情况时，这些保护功能会及时启动，避免伺服放大器及相关设备受到损坏，保障系统的安全运行。
- 模块化设计：模块化的设计不仅便于安装和集成，还使得维护和更换工作更加便捷，能够有效缩短设备的停机时间，提高设备的可用性。
英文资料：
1、 Product Overview
The model is A5-206-000 (sometimes referred to as MCD 805 A5-206-000), which belongs to the AC servo amplifier. It has a wide range of applications in the industrial field and can be used for servo control of industrial automation, CNC machine tools, packaging machinery, cranes and other equipment, providing strong support for the precise operation of these devices.
2、 Main technical parameters
Input voltage: Using three-phase AC 230V AC power supply with a frequency of 50/60Hz, it can adapt to the corresponding industrial power supply environment.
Output current: Approximately 6A, which can meet the current requirements of servo control for related equipment.
Control method: By using vector control technology, high-precision and high-speed response control effects can be achieved, ensuring the operational accuracy of the equipment.
Cooling method: Natural air cooling or forced air cooling can be selected according to actual usage to ensure that the servo amplifier maintains a suitable temperature and stable performance during operation.
Structural form: Adopting modular design, this design makes it suitable for integration into control cabinets or racks, facilitating installation and system integration.
3、 Core functions and features
High performance vector control: With the help of high-performance vector control technology, precise speed and position control can be provided to ensure that the equipment can accurately complete actions according to instructions during operation, improving the accuracy and efficiency of the equipment's work.
Wide speed regulation range: With a wide speed regulation range, it can not only meet the stability requirements of low-speed start-up of equipment, but also adapt to the fast response requirements of high-speed operation, enhancing the adaptability of equipment under different working conditions.
Multiple control interfaces: Equipped with multiple control interfaces, supporting analog and digital input, convenient for connecting with different control devices and systems, improving the compatibility and flexibility of servo amplifiers.
Built in multiple protection functions: It has multiple protection functions such as overload, overvoltage, overcurrent, and short circuit. When the device encounters abnormal situations, these protection functions will be activated in a timely manner to prevent damage to the servo amplifier and related equipment, ensuring the safe operation of the system.
Modular design: Modular design not only facilitates installation and integration, but also makes maintenance and replacement work more convenient, effectively reducing equipment downtime and improving equipment availability.
2.产 品 展 示
