Magnetek EDB4040EH动态制动电阻器
1.产 品 资 料 介 绍：
- 高功率吸收能力：能够承受变频器制动过程中产生的高能量冲击，并且可以快速消散回馈的能量，保障系统的稳定运行。
- 优良的热管理设计：采用耐高温材料制造，同时搭配合理的散热结构，确保电阻器在长期使用过程中能够稳定运行，避免因过热而出现故障。
- 紧凑坚固结构：结构设计紧凑且坚固，方便安装在控制柜内，占用空间小。同时，它能够适应工业现场的恶劣环境，具备较强的环境适应能力。
- 多种阻值和功率等级：提供多种不同的阻值和功率等级可供选择，能够根据系统的具体需求进行选配，满足不同场景下的制动要求。
- 高可靠性和安全性：符合相关的工业标准，具备良好的抗震动和抗冲击性能，在保证自身可靠运行的同时，也为整个系统的安全提供了保障。
- 变频器驱动系统：在交流变频器驱动的风机、水泵、输送机等设备中应用广泛，能够有效实现动态制动功能，确保这些设备的稳定运行。
- 起重机和搬运设备：用于桥式起重机、门式起重机、龙门吊等设备的快速减速和停止过程，可保护机械的安全，避免因制动不当而造成设备损坏。
- 冶金与矿山机械：能够适应高惯量负载的制动需求，保障冶金与矿山机械在运行过程中的稳定与安全，确保生产工作的顺利进行。
- 纺织、印刷和包装机械：可以保证高速运转的这些机械在停止时能够平稳制动，减少因制动问题对生产造成的影响，提升生产效率与产品质量。
- 电梯与升降平台：能够实现平稳制动，为电梯与升降平台上的人员和设备安全提供有力保障，降低安全事故发生的风险。
英文资料：
MAGNETEK EDB4040EH is an industrial grade dynamic braking resistor specifically designed for use in frequency converters and drive systems, responsible for energy absorption and consumption. Its main function is to convert the energy feedback from the motor into heat energy and release it when the motor performs rapid deceleration or braking operations, in order to protect the driving equipment and extend the service life of the entire system.
Product Features
High power absorption capacity: able to withstand the high-energy impact generated during the braking process of the frequency converter, and can quickly dissipate the feedback energy, ensuring the stable operation of the system.
Excellent thermal management design: Made of high-temperature resistant materials and equipped with a reasonable heat dissipation structure, ensuring that the resistor can operate stably during long-term use and avoiding malfunctions due to overheating.
Compact and sturdy structure: The structural design is compact and sturdy, making it easy to install inside the control cabinet and occupying minimal space. At the same time, it can adapt to the harsh environment of industrial sites and has strong environmental adaptability.
Multiple resistance values and power levels: Provides a variety of different resistance values and power levels to choose from, which can be selected according to the specific needs of the system to meet the braking requirements in different scenarios.
High reliability and safety: Compliant with relevant industrial standards, it has good anti vibration and anti impact performance, ensuring its reliable operation while also providing security for the entire system.
Application Fields
Variable frequency drive system: widely used in AC variable frequency drive equipment such as fans, water pumps, conveyors, etc., it can effectively achieve dynamic braking function and ensure the stable operation of these devices.
Cranes and handling equipment: used for the rapid deceleration and stopping process of bridge cranes, gantry cranes, gantry cranes and other equipment, which can protect the safety of machinery and avoid equipment damage caused by improper braking.
Metallurgical and mining machinery: capable of adapting to the braking requirements of high inertia loads, ensuring the stability and safety of metallurgical and mining machinery during operation, and ensuring the smooth progress of production work.
Textile, printing, and packaging machinery: These machines that operate at high speeds can brake smoothly when stopped, reducing the impact of braking problems on production and improving production efficiency and product quality.
Elevators and lifting platforms: capable of achieving smooth braking, providing strong protection for the safety of personnel and equipment on elevators and lifting platforms, and reducing the risk of safety accidents.
2.产 品 展 示
