GIDINGS&LEWIS M.1017.3436执行控制模块

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS M.1017.3436 执行控制模块解析

一、产品概述

二、技术参数（典型特性）

• 产品型号：M.1017.3436
• 功能定位：专注于执行器与电机驱动的工业级执行控制模块
• 控制方式：采用数字输出控制模式，兼容继电器、电磁阀、伺服驱动器等多种执行器驱动需求，可根据设备类型灵活切换驱动逻辑
• 输入接口：支持接收上位系统输出的脉冲信号（用于精准定位）、逻辑电平信号（用于开关控制）等，信号识别精度高，避免指令传输偏差
• 输出接口：具备多路输出通道，可直接驱动伺服电机、步进电机运转，或控制机械执行器（如气缸、夹紧装置）动作，满足不同负载的驱动需求
• 响应速度：搭载高动态响应电路，指令接收至输出驱动的延迟短，能快速跟随上位系统指令变化，适配高速定位、高频动作切换等控制场景
• 保护功能：内置过流保护（防止输出电流过载烧毁模块与执行器）、短路保护（电路短路时快速切断输出）、过温保护（模块温度过高时触发降额或停机），全方位保障设备安全
• 安装方式：采用模块化插槽式结构，可直接适配工业标准机柜导轨，安装无需复杂布线，后期维护时模块插拔便捷，降低系统停机时间

英文资料：

GIDINGS&LEWIS M.1017.3436 Execution Control Module Analysis

1、 Product Overview

GIDINGS&LEWIS M.1017.3436 Execution Control Module is a core control component in industrial automation systems and CNC machine tools, responsible for the key functions of "instruction reception signal conversion action drive". It can accurately receive control instructions issued by upper control systems such as PLC and CNC, convert them into executable output signals through internal signal processing, drive actuators, servo motors, and various mechanical components to move, and ultimately achieve precise motion control and standardized operation of equipment. With stable control performance, this module is widely suitable for high-precision part processing, automated assembly line production, and other scenarios that require high action accuracy. It is a key link in ensuring the efficient operation of industrial equipment.

2、 Technical parameters (typical characteristics)

Product model: M.1017.3436

Functional positioning: Focused on industrial grade execution control modules driven by actuators and motors

Control mode: adopting digital output control mode, compatible with various actuator driving requirements such as relays, solenoid valves, servo drives, etc., and can flexibly switch driving logic according to device types

Input interface: Supports receiving pulse signals (for precise positioning) and logic level signals (for switch control) output by the upper system, with high signal recognition accuracy and avoiding instruction transmission deviation

Output Interface: Equipped with multiple output channels, it can directly drive servo motors, stepper motors, or control mechanical actuators (such as cylinders, clamping devices) to meet the driving needs of different loads

Response speed: Equipped with a high dynamic response circuit, the delay from instruction reception to output drive is short, and it can quickly follow the changes in instructions from the upper system, adapting to control scenarios such as high-speed positioning and high-frequency action switching

Protection functions: Built in overcurrent protection (preventing output current overload from burning out modules and actuators), short circuit protection (quickly cutting off output in case of circuit short circuit), over temperature protection (triggering derating or shutdown when module temperature is too high), fully ensuring equipment safety in all aspects

Installation method: Adopting a modular slot structure, it can directly adapt to industrial standard cabinet rails. Installation does not require complex wiring, and module insertion and removal are convenient for later maintenance, reducing system downtime

2.产      品      展      示
