GIDINGS&LEWIS 502-03518-22直流输出模块
1.产 品 资 料 介 绍：
GIDDINGS & LEWIS 502-03518-22 直流输出模块产品特点解析
一、高精度直流输出：保障直流负载精准动作
二、多通道输出：提升系统负载驱动效率
三、高速响应：适配高速生产动态需求
英文资料：
Characteristics Analysis of GIDINGS&LEWIS 502-03518-22 DC Output Module Product
GIDINGS&LEWIS 502-03518-22 DC output module, as the "core output unit of DC control signals" in industrial automation systems, precisely adapts to the driving requirements of DC loads with seven core product characteristics, providing stable and reliable control signals for actuators, relays and other equipment, supporting efficient operation of data control machine tools, automated production lines and other scenarios. The specific characteristics are analyzed as follows:
1、 High precision DC output: ensuring precise operation of DC loads
The module has excellent high-precision DC output capability, which is the core guarantee for stable operation of DC loads. It can provide stable and accurate DC voltage (such as 0-10V, 24V) or current (such as 4-20mA) output, with an output accuracy error of ≤ 0.1% FS, which can effectively avoid load action deviation caused by output signal fluctuations. For example, in CNC machine tools, the 24V DC voltage output error of the driving electromagnetic fixture is controlled within ± 0.24V to ensure stable clamping force of the fixture and avoid displacement during workpiece processing; In an automated production line, a 4-20mA current signal is output to the servo driver to control the motor speed, with a current accuracy error of ≤ 0.02mA, ensuring stable and non fluctuating motor speed, perfectly adapting to the precise driving requirements of DC controlled loads such as actuators, relays, solenoid valves, etc., and reducing production errors caused by insufficient output accuracy.
2、 Multi channel output: improve system load driving efficiency
The module adopts a multi-channel output design, which can simultaneously drive multiple DC loads, greatly improving system control efficiency and flexibility. A single module usually supports 8-16 independent DC output channels (the specific number of channels depends on the configuration), and each channel output is independently controllable and does not interfere with each other - for example, in packaging machinery, 8 channels can be used to drive 8 DC loads such as the film feeding solenoid valve, cutting cylinder, labeling actuator, etc., without the need to add additional output modules, simplifying the system structure; At the same time, channel output parameters can be configured separately, such as one channel outputting 24V DC voltage to drive relays, and the other outputting 4-20mA current to drive regulating valves, to meet the differentiated needs of different types of loads and adapt to industrial scenarios where multiple loads work together, avoiding equipment grouping control delays caused by insufficient channels.
3、 High speed response: adapted to the dynamic demands of high-speed production
The module has excellent high-speed output response capability, which can quickly respond to control system instructions and ensure timely action of actuators and control devices. The delay from receiving control system instructions to outputting stable signals is ≤ 2ms, which can quickly drive the load to complete start stop, adjustment and other actions - in high-speed sorting production lines, when the sensor detects the material arrival signal, the module can output DC voltage to drive the sorting cylinder action within 1.5ms, ensuring accurate sorting of materials and avoiding material omission or missorting caused by response lag; In CNC machining,
2.产 品 展 示
