GIDINGS&LEWIS 502-03840-23伺服编码器

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502 - 03840 - 23 伺服编码器

一、产品基础信息

二、性能参数

1. 模拟输出：具备 3 路模拟输出通道，每路输出电流最大可达 10mA，输出电压范围为 ±10V，实际输出范围可拓展至 ±11V 。这种精准的模拟输出能力，能够为外部执行机构提供稳定、精确的控制信号，满足不同工业场景下对信号调节的需求。
2. 编码器输入：设有 2 路编码器输入通道，输入电压范围为 2.5 至 7.0VDC（最大值），在 2.5VDC 时，最小输入电流为 2.5mA。其正交信号频率最高可达 250kHz，脉冲信号频率最高可达 500kHz 。高速率的信号输入处理能力，确保了编码器能够快速、准确地捕捉设备运动的位置与速度信息，为系统反馈提供及时、精准的数据支持。
3. 直流输入：2 路直流输入通道，可承受的输入电压范围为 15 至 30VDC（最大值），为模块在不同电源环境下稳定运行提供了保障。
4. 环境适应性：拥有出色的环境适应能力，最高可耐受 55°C 的环境温度，能够在较为恶劣的工业环境中稳定工作，保障设备持续运行。
5. 产品重量：整体重量为 630 克，在保证高性能的同时，兼顾了产品的轻便性，便于安装与集成。

英文资料：

GIDINGS&LEWIS 502-03840-23 servo encoder

1、 Product basic information

GIDINGS&LEWIS 502-03840-23 servo encoder belongs to the Giddings&Lewis series products. In the field of industrial automation, it provides critical support for the precise operation of various equipment with its excellent performance. It often works in conjunction with programmable industrial computers and is an essential component for achieving precision control.

2、 Performance parameters

Analog output: Equipped with 3 analog output channels, each with a maximum output current of 10mA and an output voltage range of ± 10V, the actual output range can be extended to ± 11V. This precise analog output capability can provide stable and accurate control signals for external actuators, meeting the signal conditioning needs of different industrial scenarios.

Encoder input: There are 2 encoder input channels, with an input voltage range of 2.5 to 7.0VDC (maximum). At 2.5VDC, the minimum input current is 2.5mA. Its orthogonal signal frequency can reach up to 250kHz, and the pulse signal frequency can reach up to 500kHz. The high-speed signal input processing capability ensures that the encoder can quickly and accurately capture the position and velocity information of device motion, providing timely and accurate data support for system feedback.

DC input: 2 DC input channels, capable of withstanding input voltage range of 15 to 30VDC (maximum), providing guarantee for stable operation of the module in different power environments.

Environmental adaptability: With excellent environmental adaptability, it can withstand temperatures up to 55 ° C and work stably in harsh industrial environments to ensure the continuous operation of equipment.

Product weight: The overall weight is 630 grams, which ensures high performance while also considering the portability of the product, making it easy to install and integrate.

2.产      品      展      示
