GIDINGS&LEWIS  DSA-175-230S伺服驱动器

1.产 品 资 料 介 绍：

GIDINGS&LEWIS DSA - 175 - 230S 伺服驱动器

一、产品概述

二、技术特点

1. 标准额定输入：采用 230VAC 三相电源作为输入，这一电压标准与工业用电规范高度契合，保障了驱动器在各类工业环境中的稳定接入，无需复杂的电源适配装置，即可与工业电网无缝连接，为设备持续稳定运行提供可靠电力支持。
2. 适配多种功率电机：在输出功率方面表现卓越，可适配中功率至高功率的伺服电机。不仅能满足电机在正常工况下的连续运行需求，还具备出色的瞬时过载能力。当设备遭遇突发的高负载工况时，驱动器能够短时间内输出强大动力，确保电机不停转、设备不卡顿，维持生产流程的连续性，有效应对工业生产中的复杂工况。
3. 多元控制模式：支持位置环、速度环和转矩环闭环控制模式。位置控制模式下，通过接收外部输入的位置指令，如脉冲信号或通讯协议传输的位置数据，结合电机编码器反馈的实际位置信息，驱动器能够精确调节电机运转，使电机轴精准抵达预定位置，在精密加工、自动化装配等对位置精度要求极高的场景中发挥关键作用。速度控制模式中，用户仅需设定期望的电机转速，驱动器便会依据这一指令，通过调节电机输入电压和电流，精准调控电机转速，使其稳定运行在设定速度，适用于输送带、卷绕机等需要稳定速度输出的设备。转矩控制模式下，驱动器依据设定的转矩值，将其转化为对应的电流指令，实时监测电机实际电流与转速，通过先进的控制算法，如 PID 控制算法，确保电机输出转矩精确匹配设定值，常用于压力机、注塑机等对力矩控制精度要求高的设备。

英文资料：

GIDINGS&LEWIS DSA-175-230S servo drive

1、 Product Overview

GIDINGS&LEWIS DSA-175-230S, as a power type AC servo drive in the Giddings&Lewis series, occupies a key position in the precision control system of industrial automation equipment. Its core function is to precisely control high-performance servo motors, providing closed-loop speed, position, and torque control. With excellent control performance, it is widely used in fields such as CNC machine tools, automated production lines, and robot systems, helping these devices achieve high-speed and high-precision motion control, meeting the strict requirements of modern industrial production for equipment operation accuracy and efficiency.

2、 Technical features

Standard rated input: Using 230VAC three-phase power supply as input, this voltage standard is highly compatible with industrial electrical specifications, ensuring stable connection of the driver in various industrial environments. It can seamlessly connect with the industrial power grid without the need for complex power adaptation devices, providing reliable power support for the continuous and stable operation of the equipment.

Compatible with various power motors: It performs excellently in output power and can be adapted to servo motors with medium to high power. Not only can it meet the continuous operation requirements of the motor under normal working conditions, but it also has excellent instantaneous overload capacity. When the equipment encounters sudden high load conditions, the driver can output powerful power in a short period of time, ensuring that the motor does not stop and the equipment does not stall, maintaining the continuity of the production process, and effectively responding to complex working conditions in industrial production.

Multi control mode: Supports closed-loop control modes for position loop, speed loop, and torque loop. In position control mode, by receiving external input position commands such as pulse signals or communication protocol transmitted position data, combined with the actual position information feedback from the motor encoder, the driver can accurately adjust the motor operation, making the motor shaft reach the predetermined position accurately. It plays a key role in precision machining, automated assembly and other scenarios that require high position accuracy. In speed control mode, users only need to set the desired motor speed, and the driver will adjust the motor input voltage and current according to this command, accurately regulate the motor speed, and make it run stably at the set speed. It is suitable for equipment such as conveyor belts and winding machines that require stable speed output. In torque control mode, the driver converts the set torque value into corresponding current commands, monitors the actual current and speed of the motor in real time, and uses advanced control algorithms such as PID control algorithm to ensure that the motor output torque accurately matches the set value. It is commonly used in equipment such as pressure machines and injection molding machines that require high torque control accuracy.

2.产      品      展      示
