Motorola VME162PA-242LE嵌入式控制器

1.产 品 资 料 介 绍：

Motorola VME162PA-242LE 嵌入式控制器

一、产品概述

二、核心技术参数

1. 处理器与计算性能

• 核心 CPU：采用 Motorola MC68EC030 或 MC68030 系列 32 位微处理器，这是摩托罗拉经典的嵌入式处理器型号，具备均衡的计算性能与低功耗特性，主频适配嵌入式实时控制场景（典型主频支持 16MHz/25MHz，具体视配置而定），可高效处理多任务实时调度与数据运算。
• 协处理支持：部分版本可兼容 MC68881/MC68882 浮点协处理器（可选），提升浮点运算能力，适配需要精密计算的测试测量、运动控制场景。

2. 内存配置（可扩展、高可靠性）

3. 总线接口与扩展性

• 主总线：严格遵循 VMEbus 标准，支持 16 位 / 32 位数据传输模式，总线速率适配 VME 标准协议（最高支持 40 MB/s 传输带宽），可直接接入 VME 总线背板，与其他 VME 扩展模块（如 I/O 模块、通信模块）实现高速数据交互。

Motorola VME162PA-242LE嵌入式控制器 英文资料：

Motorola VME162PA-242LE Embedded Controller

1、 Product Overview

Motorola VME162PA-242LE is an embedded controller module based on the VMEbus (VersaModule Eurocard bus) standard architecture, belonging to Motorola's classic MVME162 series. As the core computing unit of embedded systems, it highly integrates processors, memory, bus interfaces, and basic I/O control functions, enabling basic data processing and system control without the need for additional expansion of core components. It is designed specifically for applications in industrial scenarios that require strict real-time, reliability, and stability requirements.

This controller can serve as an independent core unit and work together with various expansion modules (such as I/O modules, multiplexers, storage modules, etc.) under the VME bus architecture to form a modular and flexibly configurable embedded system. It is widely applicable to industrial automation, precision control, testing and measurement fields, and can especially meet the requirements of industrial environments with wide temperature range, strong interference, and long-term continuous operation.

2、 Core technical parameters

1. Processor and computing performance

Core CPU: Adopting Motorola MC68EC030 or MC68030 series 32-bit microprocessors, this is a classic embedded processor model from Motorola, with balanced computing performance and low power consumption characteristics. The main frequency is suitable for embedded real-time control scenarios (typical main frequency supports 16MHz/25MHz, depending on the configuration), and can efficiently handle multitasking real-time scheduling and data computation.

Co processing support: Some versions are compatible with MC68881/MC68882 floating-point co processors (optional) to enhance floating-point computing capabilities and adapt to testing, measurement, and motion control scenarios that require precise calculations.

2. Memory configuration (scalable, high reliability)

Memory Type Capacity Range Function Description

RAM (Random Access Memory) is based on 2 MB and can be expanded up to 8 MB. It uses industrial grade dynamic RAM (DRAM) or static RAM (SRAM), supports high-speed data read and write, and is used to run embedded operating systems and applications. Its expansion capability meets the requirements of low to medium complexity real-time tasks

ROM/Flash (Read Only/Flash) comes standard with 256 KB-1 MB (depending on version) for storing system firmware, bootloader, and solidified core control programs. The Flash version supports program flashing updates to meet system upgrade requirements

NVRAM (non-volatile RAM) with backup battery, typical capacity of 8 KB -32 KB. After power failure, it can save key configuration parameters, operation logs and other data. It integrates real-time clock (RTC) function, which can provide accurate timestamps for data collection time stamps and task scheduling timing

  Motorola VME162PA-242LE嵌入式控制器 产      品      展      示

 产品视频

3.其他产品

CONVERTEAM ALSTOM 029.352.157控制板
CONVERTEAM ALSTOM 029.374.091驱动器模块
CONVERTEAM ALSTOM 029.357.820控制板

4.其他英文产品

AN-X2-AB-DHRIO Communication module
KX8974c V24 HIEE320606R1 Control input module
PMA323BE HIEE300308R1 control unit module
