GIDINGS&LEWIS DSA030-230-P伺服驱动器

1.产 品 资 料 介 绍：

Giddings & Lewis DSA030 - 230 - P 伺服驱动器

产品概述

技术特点

数字化控制

功率范围

输入电源

反馈兼容性

接口设计

1. 数字输入输出接口：配备 8 路光耦隔离数字输入接口，可接收来自外部设备的各种数字控制信号，确保信号传输的稳定性和抗干扰能力；同时设有 4 路光耦隔离数字输出接口，用于向外部设备输出控制状态等数字信号。另外，还拥有 1 路继电器输出接口，能够满足一些需要较大电流驱动的外部设备控制需求。
2. 模拟接口：设置了 1 路模拟输入接口（支持 ±10V/0 - 10V 信号输入），可接收模拟量的控制信号，比如来自传感器的模拟量数据，用于实现更加精细的控制调节；1 路模拟输出接口可用于监控电机运行状态参数，如转速、扭矩等，或者在一些需要扭矩共享的系统中发挥作用。
3. 串口通信接口：具备串口通信接口（RS - 232/422/485），方便与其他设备进行数据通信，实现远程控制、参数设置以及状态监控等功能，便于将驱动器集成到更复杂的自动化控制系统中。

英文资料：

Giddings&Lewis DSA030-230-P servo drive

Product Overview

Giddings&Lewis DSA030-230-P belongs to the Centurion DSA series servo drives, mainly providing high-performance digital precision control for brushless AC servo motors. It adopts a compact design concept, integrates rich protection functions and diverse communication functions, performs well in precision motion control and industrial automation applications, and can adapt to various complex industrial production demand scenarios.

Technical Features

digital control

By utilizing advanced digital PI/PID algorithms, precise control is achieved for current, speed, and position. This algorithm enables the driver to respond very quickly while ensuring stable operation, and can quickly and accurately adjust the motor's operating status to meet the strict requirements for motor control under different working conditions.

power range

This driver supports continuous output power levels covering 0.5 kW, 1.0 kW, and 2.0 kW, which can fully meet the common power requirements of small and medium-sized servo systems. Whether it is small automation equipment or medium-sized industrial production lines, suitable power matching can be found, demonstrating good versatility.

input power

Adopting 230V AC power supply, this voltage specification is suitable for most common industrial power environments, without the need for complex power conversion equipment, making it convenient to directly connect and use in various industrial places, greatly improving the applicability and convenience of the product.

Feedback compatibility

It has strong feedback compatibility and can support various types of feedback devices such as incremental encoders, sine/cosine signals, absolute value encoders, etc. It can adapt to the feedback needs of different motor configurations. Regardless of the feedback method used by the motor, this driver can accurately obtain the position and speed information of the motor, thereby achieving precise control.

Interface Design

Digital input/output interface: equipped with 8-channel optocoupler isolated digital input interface, can receive various digital control signals from external devices, ensuring the stability and anti-interference ability of signal transmission; At the same time, there are 4 optocoupler isolated digital output interfaces for outputting digital signals such as control status to external devices. In addition, it also has one relay output interface, which can meet the control needs of some external devices that require high current drive.

Analog interface: 1 analog input interface is set up (supporting ± 10V/0-10V signal input), which can receive analog control signals, such as analog data from sensors, for more precise control and adjustment; One analog output interface can be used to monitor motor operating status parameters such as speed, torque, etc., or to play a role in some systems that require torque sharing.

2.产      品      展      示
