GIDINGS&LEWIS 502-03644-00直流输出板

1.产 品 资 料 介 绍：

Giddings & Lewis 502-03644-00 直流输出板介绍

一、产品概述

二、技术参数

1. 模块类型：明确界定为直流数字输出板，这一类型定位决定了其在控制系统中的功能方向，即专注于直流信号的输出，为后续与各类直流负载的适配奠定了基础。
2. 输出点数：采用多通道输出设计，常见的有 16 点和 32 点两种规格。多通道设计使得该模块能够同时驱动多个外部负载，大大提升了其在复杂工业自动化场景中的应用效率，可满足不同设备对输出通道数量的多样化需求。
3. 输出电压：采用直流 24V 标准工业电压。这一电压标准在工业领域应用广泛，具有良好的通用性，能够与市面上大多数工业级直流执行元件相兼容，无需额外进行电压转换，降低了设备配套的复杂度和成本。
4. 输出电流能力：每通道具备典型值约为 0.5A 的负载驱动能力。这一电流规格能够满足中小功率直流负载的驱动需求，如常见的电磁阀、小型继电器等，确保这些元件在工作时能够获得足够的电流支持，稳定发挥其功能。
5. 隔离保护：配备光电隔离功能。光电隔离能够有效切断模块内部电路与外部电路之间的电气连接，仅通过光信号进行信号传输。这种设计不仅显著提升了模块与外部电路之间的安全性，防止外部电路的故障或干扰影响模块及整个控制系统的正常运行，还大大增强了模块的抗干扰能力，确保在复杂的工业电磁环境中，输出信号的稳定性和准确性。
6. 诊断功能：设有 LED 状态指示灯。通过 LED 灯的亮灭、颜色变化等不同状态，能够直观地显示各输出通道的工作状态，如通道是否正常输出、是否存在故障等。这一功能为工作人员进行模块调试和日常维护提供了极大便利，可快速定位问题所在，缩短故障排查和修复时间。
7. 接口方式：采用标准背板连接与螺丝端子 / 插拔端子相结合的方式。标准背板连接确保了模块能够与 Giddings & Lewis PiC900 控制系统机架完美适配，实现稳定的信号传输和供电；而螺丝端子 / 插拔端子则为外部负载的接线提供了便捷条件，螺丝端子连接牢固可靠，插拔端子则便于快速接线和拆线，适应不同安装和维护场景的需求。

英文资料：

Introduction to Giddings&Lewis 502-03644-00 DC Output Board

1、 Product Overview

The Giddings&Lewis 502-03644-00 DC output board is an essential functional module in the PiC900 series control system. Its core function is to accurately convert the logic signals emitted by the controller into DC output signals that can drive external loads. During the operation of industrial automation equipment, it plays an important role in providing stable driving capabilities for solenoid valves, relays, light indicators, and other types of DC actuators. Like a "signal converter" and "power supply station", it ensures that these key components can operate stably and reliably according to the instructions of the control system, providing strong guarantees for the smooth development of industrial production.

2、 Technical parameters

Module type: It is clearly defined as a DC digital output board, which determines its functional direction in the control system, focusing on the output of DC signals and laying the foundation for subsequent adaptation to various DC loads.

Output points: Adopting a multi-channel output design, there are two common specifications: 16 points and 32 points. The multi-channel design enables the module to simultaneously drive multiple external loads, greatly improving its application efficiency in complex industrial automation scenarios and meeting the diverse requirements of different devices for the number of output channels.

Output voltage: Adopting DC 24V standard industrial voltage. This voltage standard is widely used in the industrial field and has good universality. It can be compatible with most industrial grade DC actuators on the market without the need for additional voltage conversion, reducing the complexity and cost of equipment matching.

Output current capability: Each channel has a typical load driving capability of about 0.5A. This current specification can meet the driving requirements of small and medium power DC loads, such as common solenoid valves, small relays, etc., ensuring that these components can receive sufficient current support during operation and stably perform their functions.

Isolation protection: equipped with photoelectric isolation function. Optoelectronic isolation can effectively cut off the electrical connection between the internal and external circuits of the module, and only transmit signals through optical signals. This design not only significantly improves the safety between the module and external circuits, preventing external circuit faults or interference from affecting the normal operation of the module and the entire control system, but also greatly enhances the module's anti-interference ability, ensuring the stability and accuracy of output signals in complex industrial electromagnetic environments.

Diagnostic function: equipped with LED status indicator lights. By using different states such as the on/off and color changes of LED lights, the working status of each output channel can be intuitively displayed, such as whether the channel is outputting normally and whether there is a fault. This feature provides great convenience for staff to debug modules and perform daily maintenance, quickly locating the problem and shortening the time for troubleshooting and repair.

 2.产      品      展      示
