GIDINGS&LEWIS M.1017.3098分析输入模块

1.产 品 资 料 介 绍：

Giddings & Lewis M.1017.3098 分析输入模块介绍

一、产品概述

二、产品特点

（一）高精度信号采集

1. 多类型信号适配：模块具备出色的信号兼容性，可支持电压、电流、温度传感器等多种模拟信号输入，无需额外添加信号转换设备，即可适配不同工业场景的感知需求。例如，接收压力传感器输出的 4-20mA 电流信号、液位传感器输出的 0-10V 电压信号、热电偶输出的毫伏级温度信号，全面覆盖工业生产中常见的模拟量监测参数，降低系统集成复杂度。
2. 信号调理保精度：内置专业信号调理功能，通过滤波、放大、线性化处理，消除模拟信号中的噪声干扰与非线性偏差，确保测量数据的准确性和稳定性。例如，针对工业现场常见的电磁噪声，模块通过低通滤波电路过滤高频干扰；针对微弱的热电偶信号，通过高精度放大电路提升信号强度；针对传感器本身的非线性误差，通过内置算法进行线性化补偿，将测量误差控制在 0.1% 以内，满足高精度工业控制对数据精度的严苛要求。

英文资料：

Introduction to Giddings&Lewis M.1017.3098 Analysis Input Module

1、 Product Overview

The Giddings&Lewis M.1017.3098 analysis input module is a key module in the PiC series control system for achieving precise conversion of industrial analog signals, and can be regarded as the "data translation center" between the control system and external sensors. Its core function focuses on the acquisition, conditioning, and conversion of analog signals: on the one hand, it accurately receives various analog signals output by industrial equipment, including voltage signals (such as 0-5V, 0-10V), current signals (such as 4-20mA, 0-20mA), and temperature sensor signals (such as thermocouple, thermistor output signals); On the other hand, through the built-in signal conditioning circuit (filtering, amplification, linearization processing) and analog-to-digital conversion unit, these continuously changing analog signals are converted into digital information that can be recognized and operated by the PiC controller, providing high-precision data support for subsequent control analysis and parameter adjustment.

In the field of industrial automation, this module is the core link connecting the "perception layer" (sensors) and the "control layer" (controllers), widely used in scenarios such as CNC machine tools and automated production lines. Through stable analog signal processing, it ensures that the control system can accurately sense equipment operating conditions, providing key data support for the efficiency and intelligence of industrial production.

2、 Product Features

（1） High precision signal acquisition

Multi type signal adaptation: The module has excellent signal compatibility and can support various analog signal inputs such as voltage, current, and temperature sensors. It can adapt to the sensing needs of different industrial scenarios without the need for additional signal conversion devices. For example, receiving 4-20mA current signals from pressure sensors, 0-10V voltage signals from liquid level sensors, and millivolt level temperature signals from thermocouples comprehensively covers common analog monitoring parameters in industrial production, reducing system integration complexity.

Signal conditioning ensures accuracy: Built in professional signal conditioning functions eliminate noise interference and nonlinear deviations in analog signals through filtering, amplification, and linearization processing, ensuring the accuracy and stability of measurement data. For example, in response to common electromagnetic noise in industrial sites, the module filters high-frequency interference through a low-pass filtering circuit; For weak thermocouple signals, the signal strength is enhanced through high-precision amplification circuits; In response to the nonlinear error of the sensor itself, a built-in algorithm is used for linearization compensation to control the measurement error within 0.1%, meeting the strict requirements of high-precision industrial control for data accuracy.

 2.产      品      展      示
