GIDDINGS & LEWIS 502-03510-41 输入输出模块

 GIDINGS&LEWIS 502-03510-41 输入输出模块

1.产 品 资 料 介 绍：

Giddings & Lewis 502-03510-41 输入输出模块产品特点

1. 高密度 I/O 配置：满足多信号交互需求

2. 24V DC 电压兼容：实现工业设备广泛适配

3. 模块化设计：灵活适配系统升级与扩展

英文资料：

Giddings&Lewis 502-03510-41 Input/Output Module Product Features

1. High density I/O configuration: meets the requirements of multi signal interaction

This module is equipped with a high-density configuration of 16 input channels and 8 output channels, designed specifically for automation control systems that require a large amount of digital signal interaction. In industrial scenarios, complex equipment often needs to be connected to multiple sensors and actuators simultaneously - for example, in a large automotive welding production line, more than 20 temperature, pressure, and position sensor signals need to be collected through input channels, and the start and stop actions of 10+robotic arm welding heads and conveyor belt motors need to be controlled through output channels. The multi-channel design of this module can reduce the number of modules used in a single system, avoid wiring confusion and space occupation caused by module stacking, and reduce system integration costs, making signal interaction more centralized and efficient, especially suitable for the control needs of large-scale automated production lines and complex equipment.

2. 24V DC voltage compatibility: achieving widespread adaptation of industrial equipment

The module natively supports 24V DC voltage input and output, which perfectly fits the mainstream voltage standards in the field of industrial automation. In industrial scenarios, the vast majority of sensors (such as photoelectric sensors, proximity sensors) and actuators (such as small relays, solenoid valves) are powered by 24V DC - for example, in food packaging production lines, photoelectric sensors need to output a "packaged in place" signal at 24V DC voltage, and the module can directly receive the signal and transmit it to the controller; At the same time, the 24V DC signal output by the module can directly drive the relay of the packaging sealing motor without the need for an additional voltage conversion module. This "plug and play" compatibility not only simplifies the system wiring process, but also avoids signal distortion or equipment damage caused by voltage mismatch, greatly improving the adaptability of the module to various industrial equipment.

3. Modular design: flexible adaptation to system upgrades and expansions

Adopting a standardized modular structure, it can seamlessly integrate with the core components of Giddings&Lewis control systems, such as PiC900 series CPUs, servo drives, etc. In practical applications, enterprises can build basic control systems based on initial production needs - for example, small CNC machine tools only require one I/O module in conjunction with a CPU to achieve basic machining control in the initial stage; When the production scale expands and functions such as tool magazine detection and workpiece positioning need to be added, there is no need to ｒｅｐｌａｃｅ the entire system. Only the same type of I/O module needs to be added and spliced with the original components through standard interfaces to expand the number of signal channels. This design not only reduces the technical threshold and cost of system upgrading, but also makes later maintenance more convenient - if a module fails, it can be disassembled and replaced separately, without the need to shut down the whole system for maintenance, to ensure production continuity.

2.产      品      展      示
