GIDDINGS & LEWIS 502-03459-00编码器

 GIDINGS&LEWIS 502-03459-00编码器

1.产 品 资 料 介 绍：

Giddings & Lewis 502-03459-00 编码器模块产品特点

1. 高分辨率输出：精准捕捉位置与速度信号

2. TTL 电平信号输出：实现跨设备广泛兼容

3. 多通道输出支持：满足复杂运动控制需求

英文资料：

Giddings&Lewis 502-03459-00 Encoder Module Product Features

1. High resolution output: precise capture of position and velocity signals

This encoder module has high-resolution pulse output capability and can accurately identify small position changes and velocity fluctuations, which is the core advantage of precision control scenarios. In industrial production, many fields require extremely high precision for position feedback and speed control - such as semiconductor wafer cutting equipment, which needs to cut the wafer into chips with micrometer level accuracy. The high-resolution module can provide real-time feedback on the subtle displacement of the cutting tool, ensuring that the cutting path deviation is controlled within 0.001mm; For example, in the spindle speed control of high-precision CNC machine tools, the module can capture small changes in spindle speed per minute (such as ± 1rpm) and transmit the signal to the controller to adjust the driving parameters in a timely manner, avoiding the impact of speed fluctuations on machining accuracy. This high-resolution feature allows the module to adapt to fields such as precision machining and high-end equipment manufacturing that require strict control accuracy.

2. TTL level signal output: achieving wide compatibility across devices

The module output signal adopts TTL compatible levels (typical high level value of 5V, typical low level value of 0V), perfectly matching the signal reception standards of mainstream control systems and drivers in the industrial field. In practical applications, control devices of different brands and models (such as PLCs, motion controllers) and drive devices (such as servo drives, stepper drives) mostly support TTL level signal input by default. For example, in an automated robotic arm system, the TTL signal output by the module can be directly connected to the Giddings&Lewis PiC900 controller without the need for additional signal conversion modules; At the same time, even when paired with servo drives from other brands, it can avoid signal distortion or equipment damage caused by incompatible voltage levels. This "universal" signal design significantly reduces the difficulty of system integration and enhances the adaptability range of modules.

3. Multi channel output support: meets complex motion control requirements

The module supports multi-channel output of A, B phase signals and Z reference signals, providing comprehensive signal support for complex motion control systems. A. The B-phase signal can achieve bidirectional position detection and speed calculation - for example, in the conveyor belt control of a circular assembly line, the controller can determine the running direction of the conveyor belt by the phase difference (leading or lagging by 90 °) between the A and B signals, and calculate the running speed based on the number of pulses per unit time, achieving accurate start stop and speed regulation; The Z reference signal can provide an absolute zero position reference. For example, in the positioning of the tool holder in a CNC lathe, every time the tool holder rotates to the Z signal trigger position, the system can calibrate the current position to avoid cumulative errors after long-term operation. This multi-channel design allows the module to adapt to complex motion scenarios that require direction recognition and zero position calibration, such as robotic arm handling and precision transmission.
