Giddings & Lewis 401-34201-13 DS100 伺服驱动器

 GIDINGS&LEWIS  401-34201-13 DS100  伺服驱动器

1.产 品 资 料 介 绍：

产品概述

技术参数（典型特征）

1. 输入电源：适配三相 AC 工业电源，常见的输入电压规格为 230V 或 460V，能够满足不同工业场景下的供电需求，确保在各种复杂的电力环境中稳定运行。
2. 驱动类型：属于无刷 AC 伺服驱动器，相比有刷驱动器，无刷设计具有更高的效率、更长的使用寿命以及更低的维护成本，能够适应长时间、高负荷的工作要求。
3. 控制方式：支持速度环、位置环以及转矩控制模式。速度环控制可精确调节电机的旋转速度，满足设备在不同工况下对速度的要求；位置环控制能够实现电机位置的精准定位，适用于对定位精度要求极高的应用场景；转矩控制模式则可根据负载变化实时调整电机输出转矩，确保设备运行的稳定性与可靠性。
4. 输出功率范围：主要适配中小功率伺服电机，通常输出功率在 1–7 kW 区间，能够为各类中小型工业设备提供恰到好处的动力支持，既避免了功率过大造成的能源浪费，又能确保满足设备正常运行的动力需求。
5. 保护功能：配备了完善的过压、欠压、过流以及过温保护功能。当输入电源电压过高或过低时，过压和欠压保护功能将迅速启动，防止驱动器因电压异常而损坏；过流保护功能可在电机电流超过额定值时，及时切断电路，保护驱动器和电机免受过大电流的冲击；过温保护功能则能实时监测驱动器的温度，当温度过高时自动采取降温措施或停止工作，避免因过热导致设备故障，大大提高了设备运行的安全性与可靠性。

英文资料：

Product Overview

Giddings&Lewis 401-34201-13 servo drive, as a member of the DS100 series, is tailor-made for the Centurion control platform. Its core task is to drive brushless AC servo motors, which play an irreplaceable key role in the operation of CNC systems. With excellent high response speed, it can quickly respond to control instructions and accurately regulate the operating status of the motor in a very short time; At the same time, it has excellent precision control ability, which can accurately control the speed, position, and torque of the motor, providing a solid guarantee for the efficient and stable operation of various CNC equipment.

Technical parameters (typical features)

Input power supply: Suitable for three-phase AC industrial power supply, common input voltage specifications are 230V or 460V, which can meet the power supply needs of different industrial scenarios and ensure stable operation in various complex power environments.

Drive type: Belonging to brushless AC servo drives, compared to brushed drives, brushless designs have higher efficiency, longer service life, and lower maintenance costs, and can adapt to long-term, high load work requirements.

Control mode: Supports speed loop, position loop, and torque control modes. Speed loop control can accurately adjust the rotational speed of the motor to meet the speed requirements of the equipment under different working conditions; Position loop control can achieve precise positioning of motor position, suitable for application scenarios that require extremely high positioning accuracy; The torque control mode can adjust the motor output torque in real time according to load changes, ensuring the stability and reliability of equipment operation.

Output power range: mainly suitable for small and medium power servo motors, usually with an output power in the range of 1-7 kW, which can provide just the right power support for various small and medium-sized industrial equipment. It not only avoids energy waste caused by excessive power, but also ensures that the power requirements for normal operation of the equipment are met.

Protection function: Equipped with comprehensive overvoltage, undervoltage, overcurrent, and over temperature protection functions. When the input power voltage is too high or too low, the overvoltage and undervoltage protection functions will quickly activate to prevent the driver from being damaged due to abnormal voltage; The overcurrent protection function can timely cut off the circuit when the motor current exceeds the rated value, protecting the driver and motor from the impact of excessive current; The over temperature protection function can monitor the temperature of the drive in real time, and automatically take cooling measures or stop working when the temperature is too high, avoiding equipment failure caused by overheating and greatly improving the safety and reliability of equipment operation.

 2.产      品      展      示
