FORCE COMPUTERS CPU-30Z控制器板模块

FORCE COMPUTERS CPU-30Z控制器板模块

1.产 品 资 料 介 绍：

FORCE COMPUTERS CPU-30Z控制器板模块 英文资料：

FORCE COMPUTERS CPU-30Z Embedded Single Board Controller Product Overview

FORCE COMPUTERS CPU-30Z, as a high-performance embedded single board controller (SBC) module designed for industrial scenarios, is the core hardware backbone for stable operation of industrial automation, embedded control systems, and communication platforms. Its core positioning is "high-performance computing, multi system compatibility, and adaptation to harsh environments". Through highly integrated hardware design, key functional components such as processors, memory, I/O interfaces, and bus interfaces are integrated into a single board, without the need to build complex hardware frameworks. It can be flexibly integrated into mainstream industrial bus systems such as VME, cPCI, or PC/104 as the core control unit, greatly reducing the complexity and time cost of system integration in different application scenarios, and providing efficient and stable computing power support for various industrial grade embedded tasks.

From the perspective of functional architecture, CPU-30Z is built around three core requirements: "high-speed computing+diverse interaction+stable transmission". The core computing layer is equipped with Intel or PowerPC series industrial grade processors (specific models depend on the version), combined with first/second level cache configurations, with high-speed computing and real-time control capabilities. It can efficiently handle complex control algorithms in industrial automation, data acquisition and analysis of embedded systems, and signal processing tasks of communication platforms, meeting the dual requirements of computing speed and real-time performance in industrial scenarios; The storage layer adopts a combination scheme of "onboard SDRAM+Flash/EEPROM", where the SDRAM capacity is usually 64MB~512MB and supports expansion through expansion slots to meet the temporary storage needs of a large amount of real-time data during operation. Flash/EEPROM is used to store firmware and system startup programs, ensuring that critical configuration and startup data are not lost after the device is powered off; The interaction and transmission layer integrates rich interfaces, with multiple serial ports (RS-232/RS-422/RS-485) that can interface with various sensors, actuators, and peripherals to achieve device status acquisition and control command issuance. The Ethernet interface (10/100Mbps, optional gigabit) meets the high-speed data interaction with the upper computer or remote system, and is compatible with VME, cPCI, or PC/104 bus interfaces to ensure efficient collaboration with other functional modules in the industrial system, building a complete control loop of "data acquisition processing control output status feedback".

In terms of environmental adaptation and reliability design, CPU-30Z deeply meets the stringent requirements of industrial grade scenarios: it adopts industrial grade component selection, supports wide temperature operation, can withstand fluctuations in extreme temperature environments such as high temperature workshops and outdoor low temperatures, and ensures stable performance under harsh temperature conditions; Through professional anti vibration and anti impact testing, it can adapt to production line equipment vibration, traffic equipment bumps and other working conditions,

 FORCE COMPUTERS CPU-30Z控制器板模块  产      品      展      示

 产品视频
