Extreme Networks 31019 WS-AP3965e双频系统集线器
1.产 品 资 料 介 绍：
- 设备定位：ExtremeWireless 系列户外双频无线接入点（非传统集线器，侧重无线信号覆盖与接入），主打仓储、工厂、公园、体育场等户外及严苛室内场景，适配高密度移动终端接入与长距离信号覆盖需求。
- 频段配置：支持 2.4GHz（802.11b/g/n）与 5GHz（802.11a/n/ac Wave 2）双频段并发，配备 8 个 N 型外部天线接口（每频段 4 个），可搭配全向、扇区或平板天线优化覆盖范围与容量。
- 核心功能：承担无线信号发射、终端接入与数据转发职责，支持自组织自修复 mesh 网络、动态射频管理与频谱分析，配合 ExtremeCloud IQ 实现全网集中管控，简化户外分散部署的运维难度。
- 无线性能：采用 4×4:4 MIMO 架构，双频段合计空口速率可达 2.53Gbps，支持 256 QAM 调制与多用户 MIMO（MU-MIMO），单 AP 可同时接入 250 台终端，满足高并发场景需求。
- 传输效率：配备 2 个千兆以太网端口（Active/Active 模式），有线侧吞吐量达 90,000 包 / 秒，支持 802.3at PoE + 供电（30W），无需额外部署电源线路，适配户外无市电环境。
- 覆盖优化：通过外部天线灵活调整信号方向，结合波束成形技术增强特定区域信号强度，配合动态信道选择（DCS）功能减少邻区干扰，覆盖半径较内置天线型号提升 30% 以上。
- 物理规格：户外专用外壳设计（尺寸 9.5"×8.2"×2.4"），重量 7.00 lbs，支持壁挂、抱杆等安装方式，适配户外复杂安装环境。
- 管理方式：兼容 ExtremeCloud IQ 云平台（零接触部署、拓扑监控）与 ExtremeCloud IQ-Site Engine 本地管理，支持 Web GUI/CLI 配置，需搭配固件版本 v10.01.02 及以上版本使用。
- 操作便利：配备电源、链路、频段状态指示灯，支持通过云平台远程监测信号强度、用户数量与干扰源，固件可在线升级，无需现场操作。
Extreme Networks 31019 WS-AP3965e双频系统集线器 英文资料：
1. Adaptation scenarios and functions (31019 WS-AP3965e)
Device positioning: ExtremeWireless series outdoor dual band wireless access point (non-traditional hub, focusing on wireless signal coverage and access), mainly used in outdoor and harsh indoor scenarios such as warehouses, factories, parks, sports fields, etc., suitable for high-density mobile terminal access and long-distance signal coverage needs.
Frequency band configuration: Supports dual band concurrency of 2.4GHz (802.11b/g/n) and 5GHz (802.11a/n/ac Wave 2), equipped with 8 N-type external antenna interfaces (4 per frequency band), and can be paired with omnidirectional, sector or flat panel antennas to optimize coverage range and capacity.
Core function: Responsible for wireless signal transmission, terminal access, and data forwarding, supporting self-organizing and self-healing mesh networks, dynamic RF management, and spectrum analysis, and cooperating with ExtremeCloud IQ to achieve centralized control of the entire network, simplifying the operational difficulty of outdoor decentralized deployment.
2. Performance and Access Capability (31019 WS-AP3965e)
Wireless performance: Adopting a 4 × 4:4 MIMO architecture, the total air interface rate of dual frequency bands can reach 2.53Gbps, supporting 256 QAM modulation and multi-user MIMO (MU-MIMO). A single AP can simultaneously access 250 terminals, meeting the requirements of high concurrency scenarios.
Transmission efficiency: Equipped with 2 Gigabit Ethernet ports (Active/Active mode), with a wired throughput of up to 90000 packets per second, supporting 802.3at PoE+power supply (30W) without the need for additional power lines, suitable for outdoor environments without mains power.
Coverage optimization: By flexibly adjusting the signal direction through external antennas and combining beamforming technology to enhance signal strength in specific areas, coupled with dynamic channel selection (DCS) function to reduce neighboring interference, the coverage radius is increased by more than 30% compared to the built-in antenna model.
3. Structure and Management Design (31019 WS-AP3965e)
Physical specifications: Outdoor specific shell design (size 9.5 "x 8.2" x 2.4 "), weight 7.00 lbs, supports wall mounted, pole mounted and other installation methods, suitable for complex outdoor installation environments.
Management method: Compatible with ExtremeCloud IQ cloud platform (zero touch deployment, topology monitoring) and ExtremeCloud IQ Site Engine local management, supports Web GUI/CLI configuration, and needs to be used with firmware version v10.01.02 or above.
Easy to operate: equipped with power, link, and frequency band status indicator lights, supports remote monitoring of signal strength, user count, and interference sources through the cloud platform, firmware can be upgraded online without on-site operation.
Extreme Networks 31019 WS-AP3965e双频系统集线器 产品展示
