Extreme Networks BDXA-40G12X扩展模块
1.产 品 资 料 介 绍：
- 核心适配：Extreme Networks BDXA-40G12X 是 40G 光口扩展模块，适配 ExtremeSwitching 系列高端机箱式交换机，为设备提供高密度 40G 端口扩展，满足高带宽长距离数据传输需求。
- 接口规格：配备 12 个 40GBASE-X QSFP + 光口，支持 40Gbps 传输速率，可搭配单模、多模 QSFP + 光模块，灵活适配 100 米至 40 公里等不同传输距离场景，适配数据中心核心互联需求。
- 性能支撑：采用全非阻塞线速交换架构，单端口转发速率稳定达 40Gbps，整机吞吐量高，无数据处理瓶颈，保障数据中心集群互联、大流量备份等高频高带宽业务高效运行。
- 管理兼容：无缝对接 Extreme Management Center（XMC）管理平台，支持批量配置 VLAN、QoS 流量优先级，兼容 SNMPv3 协议，可实时监控模块运行状态，实现集中化运维管控。
- 安全防护：具备硬件级 ACL 访问控制功能，可基于 IP、MAC 地址精准限制数据访问；支持端口安全绑定，防范非法设备接入，同时能抵御 ARP 欺骗、DHCP 泛洪等常见网络攻击。
- 可靠部署：支持热插拔设计，模块故障时可在线更换，无需中断整机业务；适配交换机冗余电源架构，保障供电稳定，配合链路故障快速检测机制，提升网络运行连续性。
- 运维便捷性：模块自带端口状态指示灯与全局运行指示灯，直观显示光口连接、速率及模块工作状态；支持远程故障诊断，可通过管理平台查看端口错误帧、光功率等参数，便于快速排查问题。
- 环境适应性：采用低功耗 QSFP + 光口设计，运行能耗低于同类型 40G 模块，且能在数据中心标准温湿度范围（0-40℃，20%-80% 湿度）内稳定工作，适应长期高负载运行环境。
- 组网灵活：支持链路聚合（LACP），可将多 40G 光口绑定为逻辑链路，进一步提升带宽与冗余能力；兼容 MSTP 生成树协议，构建无环网络拓扑，适配数据中心叶脊核心层、大型园区网骨干层等多场景组网。
Extreme Networks BDXA-40G12X扩展模块 英文资料：
Core Adaptation: Extreme Networks BDXA-40G12X is a 40G optical port expansion module that is compatible with the Extreme Switching series of high-end chassis switches, providing high-density 40G port expansion for devices to meet high bandwidth long-distance data transmission needs.
Interface specification: equipped with 12 40GBASE-X QSFP+optical ports, supporting 40Gbps transmission rate, can be matched with single-mode and multi-mode QSFP+optical modules, flexibly adapt to different transmission distance scenarios such as 100m to 40km, and adapt to the core interconnection requirements of the data center.
Performance support: Adopting a non blocking line speed switching architecture, the single port forwarding rate is stable at 40Gbps, with high overall throughput and no data processing bottlenecks, ensuring efficient operation of high-frequency and high bandwidth services such as data center cluster interconnection and large traffic backup.
Management compatibility: Seamless integration with the Extreme Management Center (XMC) management platform, supporting batch configuration of VLAN and QoS traffic priority, compatible with the SNPv3 protocol, and capable of real-time monitoring of module operation status, achieving centralized operation and maintenance control.
Security protection: Equipped with hardware level ACL access control function, it can accurately restrict data access based on IP and MAC addresses; Support port security binding, prevent illegal device access, and resist common network attacks such as ARP spoofing and DHCP flooding.
Reliable deployment: supports hot swappable design, can be replaced online in case of module failure, without interrupting the overall business of the machine; Adapt to the redundant power architecture of the switch, ensure stable power supply, and cooperate with the fast detection mechanism of link faults to improve network operation continuity.
Convenience of operation and maintenance: The module comes with port status indicator lights and global operation indicator lights, which intuitively display the optical port connection, speed, and module working status; Support remote fault diagnosis, allowing users to view port error frames, optical power, and other parameters through the management platform for quick troubleshooting.
Environmental adaptability: Adopting low-power QSFP+optical port design, the operating energy consumption is lower than that of the same type of 40G module, and it can work stably within the standard temperature and humidity range of data center (0-40 ℃, 20% -80% humidity), adapting to long-term high load operating environment.
Flexible networking: Supports Link Aggregation (LACP), which can bind multiple 40G optical ports into logical links, further enhancing bandwidth and redundancy capabilities; Compatible with MSTP spanning tree protocol, building an acyclic network topology, adapting to multi scenario networking such as data center spine core layer and large-scale park network backbone layer.
Extreme Networks BDXA-40G12X扩展模块 产品展示
