Extreme Networks 220-12t-10GE2电源模块
1.产 品 资 料 介 绍：
- 非 PoE 机型电源设计：Extreme Networks 220-12t-10GE2 作为非 PoE 供电的千兆接入交换机，搭载固定内置 AC 电源模块，无需为 PoE 端口分配额外供电功率，电源输出更专注于设备核心电路驱动，适配无大量供电终端的纯数据接入场景。
- 宽温环境适配能力：配合设备整体的宽温运行设计（0℃-40℃风扇停转，最高支持 50℃运行），电源模块采用耐高温元器件选型，在办公室、机房等不同温度环境下均能稳定输出功率，保障设备持续运行。
- 支持专用冗余电源模块：该交换机具备冗余电源支持能力，可扩展接入 Extreme Networks 专用的RPS 150-XT 冗余电源模块，通过冗余供电架构避免单电源故障导致的设备宕机，适配财务、业务系统等核心场景的高可用需求。
- 模块化冗余设计优势：冗余电源采用模块化插拔设计，支持热插拔操作（需配合设备电源插槽规范），运维人员可在不中断交换机运行的情况下更换电源模块，大幅降低维护窗口与业务中断风险。
- 低功耗电源优化：结合设备无 PoE 模块的硬件特性，其内置电源模块功耗较同系列 PoE 机型（如 220-12p-10GE2）更低，配合整机风扇 less 运行模式（0-40℃），形成 “低功耗电源 + 无风扇” 的节能组合，适配静音办公场景的绿色部署需求。
- 电源与堆叠功能协同：当多台 220-12t-10GE2 通过堆叠技术组成虚拟设备时，每台设备均可独立扩展冗余电源，形成分布式电源冗余体系，即便单台设备电源故障，堆叠集群仍能通过其他节点维持运行，提升整体网络可靠性。
Extreme Networks 220-12t-10GE2电源模块 英文资料：
1、 Basic power configuration and power supply characteristics
Power supply design for non PoE models: Extreme Networks 220-12t-10GE2, as a non PoE powered gigabit access switch, is equipped with a fixed built-in AC power module, eliminating the need to allocate additional power to PoE ports. The power output is more focused on driving the device's core circuit, making it suitable for pure data access scenarios without a large number of power supply terminals.
Wide temperature environment adaptability: In conjunction with the overall wide temperature operation design of the equipment (0 ℃ -40 ℃ fan shutdown, maximum support for 50 ℃ operation), the power module adopts high-temperature resistant component selection, which can stably output power in different temperature environments such as offices and computer rooms, ensuring the continuous operation of the equipment.
2、 Redundant power supply expansion and reliability assurance
Support for dedicated redundant power modules: This switch has the ability to support redundant power and can be extended to access Extreme Networks' dedicated RPS 150-XT redundant power modules. Through a redundant power supply architecture, it avoids equipment downtime caused by single power failures and adapts to high availability requirements in core scenarios such as finance and business systems.
Advantages of Modular Redundancy Design: The redundant power supply adopts a modular plug-in design, supporting hot plugging operations (in accordance with equipment power slot specifications). Operations personnel can ｒｅｐｌａｃｅ power modules without interrupting switch operation, greatly reducing maintenance windows and business interruption risks.
3、 Collaborative features of power adaptation and deployment
Low power supply optimization: Combined with the hardware characteristics of the device without PoE module, its built-in power module has lower power consumption than the same series of PoE models (such as 220-12p-10GE2). When combined with the fan less operation mode of the whole machine (0-40 ℃), it forms an energy-saving combination of "low-power power supply+fanless", which is suitable for green deployment needs in quiet office scenarios.
Collaboration between power supply and stacking function: When multiple 220-12t-10GE2 devices are formed into virtual devices through stacking technology, each device can independently expand redundant power supply, forming a distributed power supply redundancy system. Even if a single device fails, the stacking cluster can still maintain operation through other nodes, improving overall network reliability.
Extreme Networks 220-12t-10GE2电源模块 产品展示
产品视频
