Extreme Networks 220-24t-10GE2网络交换机
1.产 品 资 料 介 绍：
- 高密度千兆接入设计：Extreme Networks 220-24t-10GE2 配备 24 个 10/100/1000Base-T 电口，作为非 PoE 机型专注纯数据接入场景，可同时连接 PC、服务器、无线 AP 等 24 台终端设备，适配企业办公区、数据机房的高密度接入需求。
- 万兆上行扩展通道：机身预留 2 个 10G Base-X SFP + 光口，支持万兆光纤链路连接，相比千兆上行带宽提升 10 倍，可高效衔接核心交换机或存储设备，满足高清视频流、大数据备份等高速传输场景。
- 全端口线速转发能力：依据端口性能计算公式，24 个千兆口理论需 35.71 Mpps 转发速率，220-24t-10GE2 以 96 Gbps 交换容量与 71.4 Mpps 转发速率，实现所有千兆口与万兆口线速处理，确保数据传输无阻塞。
- 二三层融合转发架构：具备完整二层特性（VLAN、链路聚合等），同时支持 IPv4/IPv6 静态路由及 RIP 动态路由协议，可灵活划分网络网段，适配中小型企业的多层网络架构需求。
- 冗余电源扩展支持：搭载固定内置 AC 电源，同时预留冗余电源插槽，可扩展接入 Extreme 专用冗余电源模块，通过双电源并联架构实现故障自动切换，保障财务系统、业务平台等核心场景的持续供电。
- 堆叠与电源协同冗余：支持多台设备堆叠形成虚拟集群，每台 220-24t-10GE2 均可独立扩展冗余电源，构建分布式供电保障体系，单台电源故障时集群仍能通过其他节点维持运行，提升整体网络可用性。
Extreme Networks 220-24t-10GE2网络交换机 英文资料：
1、 Port configuration and expansion capability
High density gigabit access design: Extreme Networks 220-24-10GE2 is equipped with 24 10/100/1000Base-T electrical ports. As a non PoE model, it focuses on pure data access scenarios and can simultaneously connect 24 terminal devices such as PCs, servers, and wireless APs, adapting to the high-density access needs of enterprise office areas and data centers.
10 Gigabit Upstream Expansion Channel: The body is reserved with 2 10G Base-X SFP+optical ports, supporting 10 times the bandwidth of gigabit upstream links. It can efficiently connect core switches or storage devices and meet high-speed transmission scenarios such as high-definition video streaming and big data backup.
2、 Core performance and forwarding efficiency
Full port line speed forwarding capability: According to the port performance calculation formula, 24 gigabit ports theoretically require a forwarding rate of 35.71 Mpps. 220-24-10GE2 has a switching capacity of 96 Gbps and a forwarding rate of 71.4 Mpps, achieving line speed processing for all gigabit and ten gigabit ports to ensure unobstructed data transmission.
Layer 2 and 3 Fusion Forwarding Architecture: It has complete layer 2 features (VLAN, link aggregation, etc.), supports IPv4/IPv6 static routing and RIP dynamic routing protocols, and can flexibly divide network segments to meet the multi-layer network architecture needs of small and medium-sized enterprises.
3、 Reliability and redundancy design
Redundant power supply expansion support: Equipped with a fixed built-in AC power supply and reserved redundant power supply slots, it can be extended to access Extreme dedicated redundant power supply modules. Through a dual power parallel architecture, automatic fault switching is achieved to ensure continuous power supply for core scenarios such as financial systems and business platforms.
Stacking and Power Supply Collaborative Redundancy: Supports stacking multiple devices to form a virtual cluster, and each 220-24-10GE2 can independently expand redundant power supplies, building a distributed power supply guarantee system. In the event of a single power supply failure, the cluster can still maintain operation through other nodes, improving overall network availability.
Extreme Networks 220-24t-10GE2网络交换机 产品展示
