Extreme Networks SK8009-1224-F8交换机
1.产 品 资 料 介 绍：
- 混合端口密度配置：ENTERASYS SK8009-1224-F8 交换机配备 24 个 10/100/1000Base-T 铜缆端口与 8 个 1000Base-X SFP 光口，同时提供 2 个 10GbE SFP + 上行端口，端口总带宽达 68Gbps，交换容量高达 136Gbps，可满足中小企业核心层汇聚与高密度接入双重需求。
- 全千兆 PoE 供电能力：该交换机支持 IEEE 802.3af/at PoE 标准，24 个铜缆端口均具备 PoE 供电功能，总 PoE 功率预算达 370W，单端口最高输出 30W，能直接为 IP 摄像头、Wi-Fi 6 无线 AP、IP 电话等终端供电，减少额外电源布线成本。
- 多层网络冗余保障：SK8009-1224-F8 内置 IEEE 802.1d STP、802.1w RSTP 与 802.1s MSTP 生成树协议，支持 802.3ad LACP 链路聚合（每组最多 8 个端口，可配置 16 个聚合组），配合 VRRP 虚拟路由冗余协议，实现链路与路由双重冗余，保障业务零中断。
- 全方位安全防护体系：集成 802.1X 端口认证、MAC 地址绑定（单端口最多绑定 512 个 MAC）与动态 ARP 检测功能，可有效防范非法接入与 ARP 欺骗攻击；同时支持 L2-L4 层 ACL 访问控制，基于端口、IP 地址、端口号等维度精准管控流量，构建立体安全屏障。
- 智能流量管控能力：支持 802.1p 优先级标记与 DSCP 流量分类，每端口配备 8 个优先级队列，采用 WRR（加权轮询）与 SP（严格优先级）混合调度算法，确保语音、视频等关键业务优先传输，避免拥塞导致的服务降级。
- 高效运维管理支持：兼容 Web GUI 图形化管理与 CLI 命令行管理，支持 SNMPv1/v2c/v3 协议，可接入 Enterasys NetSight 管理平台实现集中监控与配置；同时具备端口镜像（支持多对一、一对一模式）与线缆检测功能，快速定位故障节点，降低运维难度。
- 组播优化处理能力：支持 IGMP v1/v2/v3 snooping 与 MLD snooping 协议，最多可管理 1024 个组播组，配合组播快速离开与组播过滤功能，精准推送视频会议、IPTV 等组播流，避免带宽浪费，提升网络资源利用率。
Extreme Networks SK8009-1224-F8交换机 英文资料：
Mixed port density configuration: The ENTERASYS SK8009-1224-F8 switch is equipped with 24 10/100/1000Base-T copper cable ports and 8 1000Base-X SFP optical ports, while providing 2 10GbE SFP+upstream ports. The total bandwidth of the ports reaches 68Gbps, and the switching capacity is up to 136Gbps, which can meet the dual needs of small and medium-sized enterprise core layer aggregation and high-density access.
Full Gigabit PoE Power Supply Capability: This switch supports the IEEE 802.3af/at PoE standard, with 24 copper ports equipped with PoE power supply. The total PoE power budget is 370W, with a maximum output of 30W per port. It can directly power IP cameras, Wi Fi 6 wireless APs, IP phones, and other terminals, reducing additional power wiring costs.
Multi layer network redundancy guarantee: SK8009-1224-F8 has built-in IEEE 802.1d STP, 802.1w RSTP, and 802.1s MSTP spanning tree protocols, supports 802.3ad LACP link aggregation (up to 8 ports per group, can configure 16 aggregation groups), and works with VRRP virtual routing redundancy protocol to achieve dual redundancy of links and routes, ensuring zero interruption of business.
Comprehensive security protection system: integrating 802.1X port authentication, MAC address binding (up to 512 MACs can be bound to a single port), and dynamic ARP detection functions, which can effectively prevent illegal access and ARP spoofing attacks; Simultaneously supporting L2-L4 layer ACL access control, accurately controlling traffic based on dimensions such as port, IP address, and port number, and building a three-dimensional security barrier.
Intelligent traffic control capability: Supports 802.1p priority tagging and DSCP traffic classification, with 8 priority queues per port, using a mixed scheduling algorithm of WRR (weighted polling) and SP (strict priority) to ensure priority transmission of critical services such as voice and video, avoiding service degradation caused by congestion.
Efficient operation and maintenance management support: compatible with Web GUI graphical management and CLI command line management, supports SNMP v1/v2 c/v3 protocols, can be integrated with Enterasys NetSight management platform for centralized monitoring and configuration; At the same time, it has port mirroring (supporting many to one and one to one modes) and cable detection functions to quickly locate faulty nodes and reduce the difficulty of operation and maintenance.
Multicast optimization processing capability: Supports IGMP v1/v2/v3 snooping and MLD snooping protocols, can manage up to 1024 multicast groups, and with multicast fast departure and multicast filtering functions, accurately pushes multicast streams such as video conferences and IPTV, avoiding bandwidth waste and improving network resource utilization.
Extreme Networks SK8009-1224-F8交换机 产品展示
产品视频
