AEG Modicon TSX3721100处理器模块

AEG MODICON TSX3721100处理器模块

1.产 品 资 料 介 绍：

1. AEG Modicon TSX3721100 作为 TSX Micro 系列模块化基座控制器，搭载工业级核心运算单元，专为中小型 OEM 设备自动化控制场景设计，稳定性与扩展性兼具。
2. 支持 24VDC 宽电压供电（适配 19.2-30V 范围），TSX3721100 抗供电微中断能力达 < 20ms，保障工业场景连续运行不中断。
3. AEG Modicon TSX3721100 内置 14Kwords RAM 与 15Kwords Flash 存储，搭配 PCMCIA 卡可扩展至 128Kwords 程序与数据存储，满足复杂控制逻辑需求。
4. 配备 3 个标准扩展槽位，TSX3721100 可灵活搭配数字量、模拟量、通信模块，最大支持 256 点 I/O 扩展，适配多样化控制需求。
5. AEG Modicon TSX3721100 集成 1 路 Uni-Telway 与 1 路 Modbus RTU 串行接口（19.2kbit/s），实现与 HMI、远程 I/O 的无缝数据交互。
6. 指令执行效率优异，布尔指令仅需 0.13μs，浮点运算 4.5μs，TSX3721100 保障控制指令实时响应，适配高速自动化场景。
7. AEG Modicon TSX3721100 支持 1 个主任务、8 个事件任务与 1 个快速任务的多任务架构，高效处理并行控制需求。
8. 工作温度覆盖 0-60℃，存储温度 - 25-70℃，湿度耐受 10-95% 无冷凝，TSX3721100 适配高低温、高湿度工业工况。
9. AEG Modicon TSX3721100 具备过载与短路双重保护机制，符合 IEC 61131-2 电磁兼容标准，抗干扰能力达 Level 3 等级。
10. 兼容 Unity Pro 编程软件，支持梯形图、结构化文本等多语言编程，TSX3721100 降低调试与二次开发门槛。
11. AEG Modicon TSX3721100 重量约 1.72kg，尺寸紧凑（参考 151×152×341.4mm），DIN 导轨安装设计节省控制柜空间。
12. 支持高达 2000 米海拔运行，TSX3721100 适配高海拔工业场景，通用性覆盖多地理环境部署需求。
13. AEG Modicon TSX3721100 通过多重国际认证，兼容 TSX Micro 系列全系列扩展模块，无缝融入现有自动化生态。
14. 广泛应用于包装机械、物料输送、OEM 设备等领域，TSX3721100 为生产线联动、设备状态控制提供核心运算支持。
15. AEG Modicon TSX3721100 提供最长 2 年质保服务，支持翻新与原厂维修，适配老旧系统升级替换与新项目集成需求。

AEG MODICON TSX3721100处理器模块 英文资料：

The AEG Modicon TSX3721100, as a modular base controller of the TSX Micro series, is equipped with an industrial grade core computing unit and is designed specifically for automation control scenarios of small and medium-sized OEM equipment. It has both stability and scalability.

Support 24VDC wide voltage power supply (suitable for 19.2-30V range), TSX3721100 has the ability to resist power supply micro interruptions up to<20ms, ensuring continuous operation in industrial scenarios without interruption.

The AEG Modicon TSX3721100 is equipped with 14Kwords RAM and 15Kwords Flash storage, which can be extended to 128Kwords program and data storage when paired with PCMCIA cards, meeting complex control logic requirements.

Equipped with 3 standard expansion slots, TSX3721100 can flexibly match digital, analog, and communication modules, supporting up to 256 point I/O expansion and adapting to diverse control needs.

The AEG Modicon TSX3721100 integrates 1 Uni Always and 1 Modbus RTU serial interface (19.2kbit/s) to achieve seamless data exchange with HMI and remote I/O.

The instruction execution efficiency is excellent, with Boolean instructions requiring only 0.13 μ s and floating-point operations requiring 4.5 μ s. The TSX3721100 ensures real-time response to control instructions and is suitable for high-speed automation scenarios.

The AEG Modicon TSX3721100 supports a multitasking architecture with 1 main task, 8 event tasks, and 1 fast task, efficiently handling parallel control requirements.

The working temperature covers 0-60 ℃, the storage temperature is -25-70 ℃, the humidity tolerance is 10-95% without condensation, and TSX3721100 is suitable for high and low temperature, high humidity industrial conditions.

The AEG Modicon TSX3721100 has a dual protection mechanism for overload and short circuit, complies with the IEC 61131-2 electromagnetic compatibility standard, and has anti-interference capability of Level 3.

Compatible with Unity Pro programming software, supporting multi language programming such as ladder diagrams and structured text, TSX3721100 reduces the threshold for debugging and secondary development.

The AEG Modicon TSX3721100 weighs approximately 1.72kg and is compact in size (reference 151 × 152 × 341.4mm). Its DIN rail installation design saves control cabinet space.

Supporting operation at altitudes up to 2000 meters, TSX3721100 is suitable for high-altitude industrial scenarios and has universality to cover deployment requirements in multiple geographical environments.

The AEG Modicon TSX3721100 has passed multiple international certifications and is compatible with the full range of TSX Micro expansion modules, seamlessly integrating into the existing automation ecosystem.

 AEG MODICON TSX3721100处理器模块 产品展示
