1.产 品 资 料 介 绍：
- CIMR-F7R4090 采用矢量控制技术，支持带 / 不带 PG 两种控制模式，0.5Hz 时可输出 150% 高启动转矩，适配重载启动场景
- 适配三相 380-480V AC 输入电压，支持 50/60Hz 宽频率输入，电压耐受范围 ±10%、频率耐受 ±5%，应对电网波动能力强
- 支持壁挂式与柜内安装两种方式，结构紧凑占用空间小，适配各类工业控制柜布局，安装灵活性高
- CIMR-F7R4090 输出容量达 140.0kVA，额定输出电流 180A，可驱动 125/150HP 电机，满足大功率设备控制需求
- 集成 DeviceNet、ProfiBus、CANopen 等现场总线选项，支持 Modbus 通信协议，与 PLC 及工控系统联动顺畅
- 工作温度覆盖 0℃~50℃，耐受湿度≤95%（无凝露），搭配 IP54 防护等级控制柜安装，适配恶劣工业环境
- CIMR-F7R4090 内置 PID 调节与 17 段多段速控制功能，支持 DROOP 功能，满足复杂工艺调速需求
- 具备 150% 额定电流 60 秒过载保护，搭配过压、过流、过热、短路多重保护，保障模块与电机安全运行
- 支持 0-400Hz 宽范围调速，速度控制精度达 1:1000，可精准适配机床、风机、水泵等设备转速需求
- CIMR-F7R4090 配备标准 LCD 操作面板，支持参数拷贝与批量配置，内置 3 种自动整定功能，调试便捷高效
CIMR-F7R4090控制器模块 英文资料：
CIMR-F7R4090 adopts vector control technology and supports two control modes with/without PG. It can output 150% high starting torque at 0.5Hz and is suitable for heavy-duty starting scenarios
Adapt to three-phase 380-480V AC input voltage, support 50/60Hz wide frequency input, voltage tolerance range ± 10%, frequency tolerance ± 5%, strong ability to cope with power grid fluctuations
Supports both wall mounted and cabinet mounted installation methods, with a compact structure and small space occupation, suitable for various industrial control cabinet layouts, and high installation flexibility
CIMR-F7R4090 has an output capacity of 140.0kVA, a rated output current of 180A, and can drive 125/150HP motors to meet the control requirements of high-power equipment
Integrate fieldbus options such as DeviceNet, ProfiBus, CANopen, etc., support Modbus communication protocol, and smoothly link with PLC and industrial control systems
Working temperature coverage of 0 ℃~50 ℃, humidity tolerance ≤ 95% (no condensation), installed with IP54 protection level control cabinet, suitable for harsh industrial environments
CIMR-F7R4090 has built-in PID regulation and 17 stage multi-stage speed control function, supports DROOP function, and meets the requirements of complex process speed regulation
Equipped with 150% rated current and 60 second overload protection, combined with multiple protections such as overvoltage, overcurrent, overheating, and short circuit, to ensure the safe operation of the module and motor
Support 0-400Hz wide range speed regulation, with a speed control accuracy of 1:1000, which can accurately adapt to the speed requirements of machine tools, fans, water pumps and other equipment
CIMR-F7R4090 is equipped with a standard LCD operation panel, supporting parameter copying and batch configuration. It has three built-in automatic tuning functions, making debugging convenient and efficient
CIMR-F7R4090控制器模块 产品展示
