1.产 品 资 料 介 绍：
- 日本原厂制造，安川 AC 伺服电机经典型号，品质工艺有严格保障。
- 永磁同步核心设计，能效比超 90%，运行能耗低，长期使用成本更经济。
- 搭载高分辨率增量式编码器，定位精度达 ±0.001mm，重复定位误差极小。
- 动态响应频率快，启停换向无迟滞，USAGED-03C22K 适配高频作业场景。
- 额定扭矩输出稳定，峰值扭矩可达额定值 3 倍，瞬时负载应对能力强。
- 防护等级达 IP65，防尘防油污，适应多粉尘、高湿度工业车间环境。
- 工作温度覆盖 - 10~55℃，宽温耐受，恶劣工况下稳定运行无压力。
- 兼容安川同系列伺服驱动器，USAGED-03C22K 系统对接无需额外适配。
- 定子绕组采用 F 级绝缘材料，耐压性能优异，电气安全有充分保障。
- 仅 0.91kg 轻量化设计（约 2.00 lbs），安装灵活性高，降低设备负载。
- 标准化法兰安装结构，USAGED-03C22K 装配简便，可直接替换同规格电机。
- 支持位置 / 速度 / 扭矩三模式控制，适配多类型工业自动化场景。
- 转子动平衡精密优化，运行噪音低于 60dB，振动小，使用寿命长。
- 宽电压输入适配（AC 220V/380V 可选），抗电网波动能力强。
- 适配机床、机械臂、自动化输送线等设备，工业应用场景广泛。
USAGED-03C22K伺服电机 英文资料：
Made in Japan, this classic model of Yaskawa AC servo motor has strict quality and craftsmanship guarantees.
The permanent magnet synchronous core design has an energy efficiency ratio of over 90%, low operating energy consumption, and more economical long-term use costs.
Equipped with a high-resolution incremental encoder, the positioning accuracy reaches ± 0.001mm, and the repeated positioning error is extremely small.
Fast dynamic response frequency, no delay in start stop commutation, USAGED-03C22K is suitable for high-frequency operation scenarios.
The rated torque output is stable, and the peak torque can reach three times the rated value, with strong ability to cope with instantaneous loads.
The protection level reaches IP65, dustproof and oil proof, suitable for industrial workshop environments with high dust and humidity.
Working temperature coverage -10~55 ℃, wide temperature tolerance, stable operation under harsh working conditions without pressure.
Compatible with Yaskawa servo drives of the same series, the USAGED-03C22K system does not require additional adaptation for docking.
The stator winding is made of F-grade insulation material, which has excellent voltage resistance and sufficient electrical safety guarantee.
Only 0.91kg lightweight design (approximately 2.00 lbs), high installation flexibility, and reduced equipment load.
Standardized flange installation structure, USAGED-03C22K is easy to assemble and can directly ｒｅｐｌａｃｅ motors of the same specification.
Support position/speed/torque three mode control, adapt to multiple types of industrial automation scenarios.
Precise optimization of rotor dynamic balance, operating noise below 60dB, low vibration, and long service life.
Wide voltage input adaptation (AC 220V/380V optional), strong resistance to grid fluctuations.
Suitable for machine tools, robotic arms, automated conveyor lines and other equipment, with a wide range of industrial application scenarios.
USAGED-03C22K伺服电机 产品展示
产品视频
