1.产 品 资 料 介 绍：
- 本特利内华达（BENTLY Nevada）旗下 DCS 监测系统专用控制器模块，核心作用是接收振动、位移等传感器信号，实现工业设备运行状态的实时监测、数据处理与故障预警
- 品牌：美国本特利（BENTLY），适配系统：兼容本特利 3500/1771 系列监测系统，标配适配 21500 系列振动探头（型号 21500-00-20-10-02）
- 产品状态：全新原装与测试合格二手件均有供应，第三方渠道现货充足（供货总量可达 7 片 / 批），部分供应商提供 3 年质保服务
- 信号处理：支持振动、位移、转速等多类型传感器输入，信号采样率高，数据处理延迟低，测量精度符合工业监测标准
- 结构规格：模块化设计，适配标准 DCS 控制柜安装，外壳采用工业级防护材质，参考尺寸兼容本特利 3500 系列模块安装规范（紧凑式布局，节省柜内空间）
- 接口与通信：配备微型公头同轴连接器，支持与系统前置器、延伸电缆无缝对接，兼容本特利专用通信协议，可接入工厂分布式控制系统
- 防护与环境：工作温度 - 40℃~85℃，存储温度 - 55℃~100℃，相对湿度≤95%（无结露），抗电磁干扰性能符合工业 EMC 标准，适配恶劣工业环境
- 核心功能：内置设备故障诊断算法，支持实时数据采集、趋势分析、报警阈值设定；具备自诊断功能，可监测模块自身运行状态，保障监测系统可靠性
- 应用场景：火电 / 水电发电机组、燃气轮机、压缩机、泵类、风机等旋转机械的状态监测，广泛应用于电力、石油化工、冶金、轨道交通等行业
- 替代与兼容：同系列扩展型号为 21500-00-20-05-02（不同探头适配版本），功能替代型号可选用本特利 3500/42M 振动监测模块；与本特利 21500 系列延伸电缆、加速度计等配件配套使用性能最优
21500控制器模块 英文资料：
1、 Core positioning
The dedicated controller module for the DCS monitoring system under Bentley Nevada is designed to receive signals from sensors such as vibration and displacement, enabling real-time monitoring, data processing, and fault warning of industrial equipment operation status
Brand: BENTLY, compatible with Bentley 3500/1771 series monitoring system, standard with 21500 series vibration probe (model 21500-00-20-10-02)
Product status: Both brand new original and tested second-hand parts are available, and third-party channels have sufficient stock (with a total supply of up to 7 pieces/batch). Some suppliers provide a 3-year warranty service
2、 Key parameters
Signal processing: Supports multiple types of sensor inputs such as vibration, displacement, and speed, with high signal sampling rate, low data processing delay, and measurement accuracy that meets industrial monitoring standards
Structural specifications: Modular design, compatible with standard DCS control cabinet installation, shell made of industrial grade protective material, reference size compatible with Bentley 3500 series module installation specifications (compact layout, saving cabinet space)
Interface and Communication: Equipped with miniature male coaxial connectors, it supports seamless integration with system front-end processors and extension cables, compatible with Bentley proprietary communication protocols, and can be connected to factory distributed control systems
Protection and Environment: Working temperature -40 ℃~85 ℃, storage temperature -55 ℃~100 ℃, relative humidity ≤ 95% (no condensation), anti electromagnetic interference performance meets industrial EMC standards, suitable for harsh industrial environments
3、 Core functions and applications
Core function: Built in device fault diagnosis algorithm, supporting real-time data collection, trend analysis, and alarm threshold setting; Equipped with self diagnostic function, it can monitor the operating status of the module itself, ensuring the reliability of the monitoring system
Application scenarios: State monitoring of rotating machinery such as thermal/hydroelectric generators, gas turbines, compressors, pumps, and fans, widely used in industries such as power, petrochemicals, metallurgy, and rail transit
Substitution and compatibility: The same series expansion model is 21500-00-20-05-02 (different probe adaptation versions), and the functional substitution model can choose Bentley 3500/42M vibration monitoring module; The best performance is achieved when used in conjunction with Bentley 21500 series extension cables, accelerometers, and other accessories
21500控制器模块 产品展示
产品视频
