1.产 品 资 料 介 绍：
- 品牌与归属：丹麦丹佛斯（Danfoss）VLT® AutomationDrive 系列高端伺服变频器，专为高精度工业运动控制场景设计，主打矢量控制性能与宽范围适配能力
- 核心作用：实现交流电机的电压 / 频率可变调节，精准控制电机转速、转矩及位置，兼顾动态响应与运行稳定性，适配中大功率工业设备
- 产品状态：全新原装件为主流供应，部分渠道提供拆机测试件，原装产品标配 12 个月质保，第三方供应商支持安装调试指导服务
- 供电与输出：
- 输入规格：三相 AC 380-480V，频率 50/60Hz±5%，电压允许波动范围 ±10%
- 输出性能：额定输出电流 23A（重载）/30A（轻载），最大输出频率 120Hz，支持 0.5Hz 低频 180% 转矩输出（开环矢量模式）
- 控制精度：速度控制精度 ±0.05%（闭环矢量），频率分辨率 0.01Hz，位置控制精度取决于编码器反馈精度
- 结构与防护：
- 物理规格：书本式紧凑设计，重量约 4.2kg，适配 19 英寸标准机柜安装（机柜深度≥300mm）
- 防护等级：IP20 防护标准，需安装在清洁、无积水的室内机房，避免粉尘直接接触
- 接口与通信：
- 控制接口：标配模拟量输入（0-10V/4-20mA）、数字量 I/O 端子，支持正转 / 反转 / 点动 / 复位等基础控制
- 通信协议：兼容 Modbus RTU、Profibus-DP 等主流工业总线，支持 RS-485 通信接口（波特率可配置）
- 反馈支持：适配增量式 / 绝对值编码器（推荐 2500 线增量编码器），信号接口兼容主流伺服电机反馈协议
- 控制模式：支持 V/F 控制、开环矢量控制、闭环矢量控制、转矩控制四种核心模式，可根据负载特性切换
- 特色功能：
- 转矩管理：支持转矩提升（初始值 5% 可微调）、转矩限制（驱动转矩 80%-120% 额定值），适配冲击负载
- 频率优化：具备多段跳频功能（可设置 3-5Hz 跳变带宽），避免机械共振；支持 8-16 段速预置
- 保护机制：内置过流、过压、欠压、过热、缺相保护，电机热保护可通过参数配置（Ith 计算法）
- 动态性能：加减速时间可精准设定（0.1-3600s），支持 S 曲线启动（重载建议 30% S 曲线），减少启动冲击
1、 Core positioning
Brand and affiliation: Danfoss VLT from Denmark ® The Automation Drive series high-end servo frequency converter is designed specifically for high-precision industrial motion control scenarios, with a focus on vector control performance and wide range adaptability
Core function: To achieve variable voltage/frequency regulation of AC motors, accurately control motor speed, torque, and position, balance dynamic response and operational stability, and adapt to medium and high-power industrial equipment
Product status: New original parts are the mainstream supply, and some channels provide disassembly test parts. Original products come with a 12-month warranty as standard, and third-party suppliers support installation and debugging guidance services
2、 Key parameters
Power supply and output:
Input specifications: three-phase AC 380-480V, frequency 50/60Hz ± 5%, allowable voltage fluctuation range ± 10%
Output performance: Rated output current of 23A (heavy load)/30A (light load), maximum output frequency of 120Hz, supporting 0.5Hz low-frequency 180% torque output (open-loop vector mode)
Control accuracy: Speed control accuracy ± 0.05% (closed-loop vector), frequency resolution 0.01Hz, position control accuracy depends on encoder feedback accuracy
Structure and Protection:
Physical specifications: book style compact design, weighing approximately 4.2kg, suitable for installation in a 19 inch standard cabinet (cabinet depth ≥ 300mm)
Protection level: IP20 protection standard, needs to be installed in a clean, water free indoor computer room to avoid direct contact with dust
Interface and Communication:
Control interface: comes standard with analog input (0-10V/4-20mA) and digital I/O terminals, supporting basic controls such as forward/reverse/jog/reset
Communication Protocol: Compatible with mainstream industrial buses such as Modbus RTU and Profibus DP, supporting RS-485 communication interface (baud rate configurable)
Feedback support: Compatible with incremental/absolute encoders (recommended 2500 line incremental encoder), signal interface compatible with mainstream servo motor feedback protocols
3、 Core functions and control modes
Control mode: Supports four core modes: V/F control, open-loop vector control, closed-loop vector control, and torque control, which can be switched according to load characteristics
Featured features:
Torque management: Supports torque increase (initial value 5% adjustable), torque limitation (driving torque 80% -120% rated value), and adapts to impact loads
Frequency optimization: equipped with multi segment frequency hopping function (adjustable 3-5 Hz hopping bandwidth) to avoid mechanical resonance; Support 8-16 speed preset
Protection mechanism: Built in overcurrent, overvoltage, undervoltage, overheating, phase loss protection, motor thermal protection can be configured through parameters (Ith calculation method)
Dynamic performance: The acceleration and deceleration time can be accurately set (0.1-3600s), supporting S-curve startup (recommended 30% S-curve for heavy loads), and reducing startup shock
EVS9323-EP伺服变频器 产品展示
产品视频
