1.产 品 资 料 介 绍：
- 8 槽高扩展架构：NI PXI-1042 采用 8 插槽标准 PXI 背板设计，含 3 个双槽与 3 个单槽 filler 面板，预留充足扩展空间适配多模块组合。
- 双标准兼容设计：NI PXI-1042 插槽同时支持 3U PXI 与 3U CompactPCI 模块接入，无需额外适配即可兼容两类标准设备。
- 高精度时钟同步：插槽集成 10MHz 低抖动参考时钟，槽间同步偏差小于 250ps，时钟精度达 ±25ppm，保障多模块协同测量精度。
- 多触发总线集成：每个插槽均支持 PXI 触发总线、星形触发与模块间本地总线，满足复杂测试场景的同步触发需求。
- 智能温控散热：插槽区域配备过滤强制风冷系统，支持自动 / 高速两档风扇调节，通过 slot blockers 优化风道，避免模块过热。
- 宽温域稳定运行：NI PXI-1042 插槽工作温度覆盖 0℃~55℃，存储温度范围 - 20℃~70℃，适应实验室与工业现场多环境。
- 快速维护设计：插槽对应的电源与风扇集成模块化单元，拆卸更换耗时小于 5 分钟，显著降低维护停机时间。
- 外部时钟扩展：通过背板 BNC 接口支持外部 10MHz 时钟输入 / 输出，可实现多台 PXI-1042 chassis 集群同步运行。
- 高可靠性认证：插槽背板符合 UL94V-0 安全标准，经 halt 测试验证，抗冲击达 30g 峰值，随机振动耐受 0.31grms（工作状态）。
- 灵活安装适配：支持前后机架式安装（4U 高度），插槽布局适配便携式测试系统与固定实验室平台，兼容多场景部署需求。
8-slot high expansion architecture: NI PXI-1042 adopts an 8-slot standard PXI backplane design, including 3 dual slot and 3 single slot filler panels, with sufficient expansion space reserved to accommodate multiple module combinations.
Dual standard compatible design: The NI PXI-1042 slot supports both 3U PXI and 3U CompactPCI module access, making it compatible with both types of standard devices without the need for additional adaptation.
High precision clock synchronization: The slot integrates a 10MHz low jitter reference clock, with a synchronization deviation between slots of less than 250ps and a clock accuracy of ± 25ppm, ensuring the accuracy of multi module collaborative measurement.
Multi trigger bus integration: Each slot supports PXI trigger bus, star trigger, and local bus between modules, meeting the synchronous triggering requirements of complex testing scenarios.
Intelligent temperature control and heat dissipation: The slot area is equipped with a filtered forced air cooling system, which supports automatic/high-speed fan adjustment. The air duct is optimized through slot blockers to avoid module overheating.
Stable operation over a wide temperature range: The NI PXI-1042 slot operates at temperatures ranging from 0 ℃ to 55 ℃, with a storage temperature range of -20 ℃ to 70 ℃, making it suitable for multiple environments in laboratories and industrial sites.
Quick maintenance design: The power supply and fan integrated modular unit corresponding to the slot can be disassembled and replaced in less than 5 minutes, significantly reducing maintenance downtime.
External clock expansion: Supports external 10MHz clock input/output through the backplane BNC interface, enabling synchronous operation of multiple PXI-1042 chassis clusters.
High reliability certification: The slot backplate meets the UL94V-0 safety standard and has been verified by the HALT test to have a peak impact resistance of 30g and a random vibration tolerance of 0.31grms (working state).
Flexible Installation Adaptation: Supports front and rear rack mounted installation (4U height), slot layout adaptation for portable testing systems and fixed laboratory platforms, compatible with multi scenario deployment requirements.
