1.产 品 资 料 介 绍：
- 0.2S 级高精度计量：ICWR243X5563 准确度达 0.2S 级，在 1%~120% 额定电流范围内误差≤±0.2%，相位差≤±10′，适配负荷波动大的计量场景，数据支撑精准可靠。
- 宽量程定制适配：额定一次电流覆盖 5A~2000A 可选，变比可按需定制，二次侧标准输出 5A/1A，满足工业配电、光伏电站等多场景电流监测需求。
- 开合式免断安装：采用拆分式铁芯结构，通过 304 不锈钢卡箍紧固，无需断开主电路即可环绕导线安装，大幅降低施工难度与停机损失。
- 高绝缘安全防护：绝缘等级达 Class 0.66，隔离电压≥4242Vdc，额定短时热电流 31.5kA/1s，铁芯与二次侧双接地设计，杜绝高压窜入风险。
- 宽温域稳定运行：工作温度范围 - 40℃~+85℃，相对湿度≤95% 无冷凝，采用耐高温材料与密封工艺，适配户外、高低温等极端工业环境。
- 强抗干扰电磁屏蔽：外壳采用 UL94 V-0 级阻燃工程塑料，内置金属屏蔽层与优化磁路设计，降低电磁耦合干扰，确保信号输出线性稳定。
- 二次侧防开路保护：标配短路保护端子与防开路保护器，未接负载时自动短接二次绕组，避免开路产生数千伏高压，保障人员与设备安全。
- 多标准合规认证：符合 IEC 61869-1、EN 60044-1 等国际标准，通过 CE、ROHS 认证，满足电网计量、工业保护等场景的合规要求。
- 紧凑型灵活安装：支持 35mm 标准 DIN 导轨安装，窗口内径适配多种规格母排与电缆，体积小巧不占空间，适配开关柜、环网柜等紧凑布局。
- 低损耗长寿命设计：采用高导磁率进口硅钢片磁芯，磁滞损耗与涡流损耗低，经真空浇注工艺封装，防潮湿抗老化，MTBF 超 300K 小时。
ICWR243X5563电流变压器 英文资料：
0.2S level high-precision measurement: ICWR243X5563 has an accuracy of 0.2S level, with an error of ≤± 0.2% and a phase difference of ≤± 10 ′ within the rated current range of 1%~120%. It is suitable for measurement scenarios with large load fluctuations and provides accurate and reliable data support.
Wide range customization and adaptation: The rated primary current covers 5A~2000A, and the transformation ratio can be customized according to needs. The secondary side standard output is 5A/1A, which meets the current monitoring needs of multiple scenarios such as industrial distribution and photovoltaic power stations.
Open and close installation: Adopting a split iron core structure, fastened with 304 stainless steel clamps, it can be installed around the wires without disconnecting the main circuit, greatly reducing construction difficulty and downtime losses.
High insulation safety protection: The insulation level reaches Class 0.66, the isolation voltage is ≥ 4242VDC, the rated short-time thermoelectric current is 31.5kA/1s, and the iron core and secondary side are designed with double grounding to eliminate the risk of high voltage intrusion.
Wide temperature range stable operation: working temperature range -40 ℃~+85 ℃, relative humidity ≤ 95%, no condensation, using high temperature resistant materials and sealing technology, suitable for extreme industrial environments such as outdoor, high and low temperatures.
Strong anti-interference electromagnetic shielding: The shell is made of UL94 V-0 grade flame-retardant engineering plastic, with a built-in metal shielding layer and optimized magnetic circuit design to reduce electromagnetic coupling interference and ensure linear and stable signal output.
Secondary side anti open circuit protection: Equipped with short-circuit protection terminals and anti open circuit protectors, it automatically short circuits the secondary winding when no load is connected, avoiding thousands of volts of high voltage caused by open circuits and ensuring the safety of personnel and equipment.
Multi standard compliance certification: Complies with international standards such as IEC 61869-1 and EN 60044-1, and has passed CE and ROHS certifications to meet compliance requirements in scenarios such as power grid metering and industrial protection.
Compact and flexible installation: Supports 35mm standard DIN rail installation, with window inner diameter compatible with various specifications of busbars and cables, compact size that does not take up space, suitable for compact layouts such as switchgear and ring main units.
Low loss and long life design: imported silicon steel core with high permeability is adopted, which has low hysteresis loss and eddy current loss. It is sealed by vacuum casting process, moisture proof and anti-aging, and MTBF exceeds 300K hours.
