810-495586-001联锁板

810-495586-001联锁板

1.产 品 资 料 介 绍：

810-495586-001联锁板相关说明

1. 810-495586-001为标准化联锁板型号，适配开关设备柜门联锁系统，参数指标精准匹配工业级应用需求

2. 采用压铸锌材质主体，表面经粉末喷涂处理，颜色为RAL 7037灰色，兼具优良的机械强度与抗腐蚀性能

3. 核心锁扣采用单扣式设计，锁扣部件为铁镀锌材质搭配金属弹簧，锁止牢固，解锁顺畅，保障联锁可靠性

4. 支持底部出线方式，线缆布置规整，可减少线路缠绕干扰，适配开关设备内部紧凑的布线空间

5. 工作温度范围广泛，可稳定适应-40℃至125℃的极端环境，适配高温、低温等各类恶劣工业作业场景

6. 防护等级达IP65（符合IEC 60529标准，联锁状态下），可有效防尘、防水溅，保障在潮湿多尘环境下的稳定运行

7. 可与断路器、接地/隔离开关联锁杆无缝配合，实现正反向闭锁一体功能，正向闭锁强度高，反向闭锁可靠

8. 板体采用模块化设计，孔位定位精准，可与开关设备柜门及内部机构精准对接，无需额外改装即可顺利装配

9. 内置复位弹簧结构，联锁动作后可自动复位，保障联锁逻辑的连贯性，减少人工复位操作，提升设备运行效率

10. 主要应用于开关设备柜门联锁系统，可实现“五防”安全功能，防止误入带电间隔、带负荷操作等危险工况

11. 配套微动开关组件，可实时检测柜门状态，柜门打开后能将位置信号传输至控制保护回路，实现电气闭锁联动

12. 所有金属部件均经过严格的防锈处理，长期使用不易锈蚀，可大幅提升联锁板的使用寿命与环境适应性

13. 安装需由专业人员操作，安装前需确认产品完好性及型号匹配度，严格遵循手册要求固定，确保联锁功能正常

14. 禁止在易燃易爆气体环境、潮湿凝露环境中安装使用，操作时需保持手部干燥，避免触碰导电部件，保障使用安全

15. 出厂前经过机械性能测试、防护等级测试、高低温环境测试等全面检测，确保每一件产品均符合工业安全标准

810-495586-001联锁板 英文资料：

810-495586-001 Interlocking board related instructions

810-495586-001 is a standardized interlocking board model that is compatible with switchgear cabinet door interlocking systems, with parameter indicators accurately matching industrial grade application requirements

2. The main body is made of die cast zinc material, and the surface is treated with powder coating. The color is RAL 7037 gray, which combines excellent mechanical strength and corrosion resistance

3. The core lock adopts a single buckle design, and the lock components are made of iron galvanized material with metal springs, which lock firmly and unlock smoothly, ensuring the reliability of interlocking

4. Support bottom outlet method, orderly cable layout, can reduce line winding interference, and adapt to the compact wiring space inside the switchgear

5. With a wide range of working temperatures, it can stably adapt to extreme environments ranging from -40 ℃ to 125 ℃, and is suitable for various harsh industrial operation scenarios such as high and low temperatures

6. The protection level reaches IP65 (in accordance with IEC 60529 standard, in interlocking state), which can effectively prevent dust and splashes, ensuring stable operation in humid and dusty environments

7. It can seamlessly cooperate with circuit breakers, grounding/isolating switch interlocking rods to achieve the integrated function of forward and reverse locking. The forward locking strength is high, and the reverse locking is reliable

8. The board adopts a modular design, with precise hole positioning, which can be accurately connected to the switchgear cabinet door and internal mechanism, and can be assembled smoothly without additional modification

9. Built in reset spring structure, which can automatically reset after interlocking action, ensuring the continuity of interlocking logic, reducing manual reset operations, and improving equipment operation efficiency

10. Mainly used in the interlocking system of switchgear cabinet doors, it can achieve the "five prevention" safety function, prevent accidental entry into live intervals, load operation and other dangerous working conditions

11. Equipped with micro switch components, it can detect the status of the cabinet door in real time. After the cabinet door is opened, the position signal can be transmitted to the control and protection circuit to achieve electrical interlocking linkage

12. All metal components have undergone strict rust prevention treatment, making them less prone to rusting after long-term use, which can significantly improve the service life and environmental adaptability of the interlocking board

13. Installation must be carried out by professional personnel. Before installation, it is necessary to confirm the integrity and model matching of the product, strictly follow the manual requirements for fixing, and ensure that the interlocking function is normal

14. It is prohibited to install and use in flammable and explosive gas environments, humid and condensed environments. During operation, hands should be kept dry to avoid touching conductive parts and ensure safe use

15. Before leaving the factory, it undergoes comprehensive testing such as mechanical performance testing, protection level testing, and high and low temperature environment testing to ensure that each product meets industrial safety standards
