1.产 品 资 料 介 绍：

SE6000H-US000B逆变器产品说明

SE6000H-US000B是SolarEdge公司推出的单相储能型逆变器，隶属于Energy Hub系列，核心定位为住宅及小型商业场景的光伏储能系统核心组件，集成光伏电能转换、电池储能管理、备用供电及智慧能源调控功能，凭借HD-Wave技术实现高效能与高可靠性，广泛适配分布式光伏储能应用。以下为其核心信息梳理：

一、核心技术特性

- 高效电能转换：采用HD-Wave技术，最大逆变效率达99%，CEC加权效率98.5%，直流超量200%设计，最大直流输入功率可达12000W，能量转换损耗极低；

- 全场景功率适配：额定交流输出功率6000W，最大连续输出电流27.5A（@220V），总谐波失真<3%，功率因数可在-0.85至0.85间调节，适配电网并联与备用供电双场景；

- 智慧储能与备份：支持最多3个SolarEdge Energy Bank电池组联动，备电模式额定交流功率6000W（单台设备备电为90%），可为住宅整体或局部区域提供应急供电，备电电压范围194-264Vac；

- 全方位安全防护：整合电弧故障保护与直流快速关断功能，符合NEC 2014/2017/2020相关规范；具备反极性保护、600kΩ灵敏度接地故障绝缘检测，防护等级达NEMA 4，适应户外恶劣环境；

- 多元通信与智能调控：支持RS485、以太网、可选Wi-Fi及SolarEdge Energy Net通信，可通过SetApp手机程序本地调试；内建计费级发电量电表（符合ANSI C12.20 Class 0.5规范），支持耗電量監控，可直接对接智能电动车充电桩；

- 工业级环境适配：工作温度范围-40～+60℃，采用自然对流冷却，运行噪音<25dBA，体积小巧（450×370×174mm），重量仅11.8kg，支持室内外壁装或吊顶安装，安装维护便捷。

二、核心应用领域

- 住宅分布式光伏储能：适配家庭光伏电站，实现光伏电能的高效转换、剩余电能存储，以及电网停电时的备用供电，降低家庭用电成本，提升能源自给率；

- 小型商业光伏系统：适用于小型商铺、办公楼等场景的分布式光伏项目，结合储能功能实现峰谷电价套利，优化能源使用结构，降低商业用电开销；

- 智慧能源社区：作为社区微电网的核心组件，协同多户光伏与储能设备，实现能源的分布式调度、余电共享，支撑社区能源智能化管理；

- 偏远地区供电保障：为电网覆盖薄弱的偏远住宅、乡村民宿等场景提供“光伏+储能”一体化供电解决方案，兼顾常规用电与应急备电需求。

SE6000H-US000B逆变器 英文资料：

SE6000H-US000B Inverter Product Description

SE6000H-US000B is a single-phase energy storage inverter launched by SolarEdge, belonging to the Energy Hub series. It is positioned as the core component of photovoltaic energy storage systems for residential and small commercial scenarios, integrating photovoltaic energy conversion, battery energy storage management, backup power supply, and smart energy regulation functions. With HD Wave technology, it achieves high efficiency and reliability, and is widely compatible with distributed photovoltaic energy storage applications. The following is a summary of its core information:

1、 Core technical characteristics

-Efficient energy conversion: using HD Wave technology, the maximum inverter efficiency reaches 99%, CEC weighted efficiency is 98.5%, DC excess design is 200%, the maximum DC input power can reach 12000W, and the energy conversion loss is extremely low;

-Full scenario power adaptation: rated AC output power of 6000W, maximum continuous output current of 27.5A (@ 220V), total harmonic distortion<3%, power factor adjustable between -0.85 and 0.85, suitable for dual scenarios of grid parallel and backup power supply;

-Smart energy storage and backup: Supports up to 3 SolarEdge Energy Bank battery packs linked together, with a rated AC power of 6000W in backup mode (90% backup power for a single device), providing emergency power supply for the entire or partial residential area, with a backup voltage range of 194-264Vac;

-Comprehensive safety protection: integrating arc fault protection and DC fast shutdown function, in compliance with NEC 2014/2017/2020 relevant specifications; Equipped with reverse polarity protection, 600k Ω sensitivity grounding fault insulation detection, with a protection level of NEMA 4, suitable for harsh outdoor environments;

-Diversified communication and intelligent control: supports RS485, Ethernet, optional Wi Fi, and SolarEdge Energy Net communication, and can be debugged locally through SetApp mobile program; Built in billing level power generation meter (compliant with ANSI C12.20 Class 0.5 standard), supports power consumption monitoring, and can be directly connected to intelligent electric vehicle charging stations;

-Industrial grade environment adaptation: Operating temperature range of -40~+60 ℃, using natural convection cooling, operating noise<25dBA, compact size (450 × 370 × 174mm), weight only 11.8kg, supports indoor and outdoor wall installation or ceiling installation, easy installation and maintenance.

2、 Core application areas

-Residential distributed photovoltaic energy storage: adapted to household photovoltaic power stations, achieving efficient conversion of photovoltaic energy, storage of surplus energy, and backup power supply in case of power outages, reducing household electricity costs, and improving energy self-sufficiency;

-Small commercial photovoltaic system: suitable for distributed photovoltaic projects in small shops, office buildings and other scenarios, combined with energy storage function to achieve peak valley electricity price arbitrage, optimize energy use structure, and reduce commercial electricity consumption expenses;

 SE6000H-US000B逆变器  产品展示

产品视频
