3123634-1电源板

3123634-1电源板

1.产 品 资 料 介 绍：

3123634-1电源板产品特点

1. 采用高品质FR-4基材，玻璃化温度（Tg）≥150℃，具备优异的耐高温性与力学稳定性，适配工业电源高温工作环境。

2. 搭载高效DC-DC转换电路，转换效率高达95%以上，能耗低且无需额外风扇散热，节能效果显著。

3. 支持宽电压输入设计，适配8-32Vdc宽幅输入，抗电压波动能力强，可适应多种工业电源系统。

4. 具备多路精准输出功能，可稳定提供5V、12V、24V等多种电压，满足不同负载的供电需求。

5. 采用独立电源层与接地层布线设计，配合阻抗控制技术，有效降低信号串扰与电磁干扰，保障供电稳定性。

6. 集成过流、过压、欠压、短路多重保护机制，故障时快速响应切断供电，全面防护后端设备安全。

7. 具备过温保护功能，内置温度传感器，温度异常时自动触发保护，避免器件因过热损坏。

8. 采用化学沉金表面处理工艺，触点抗氧化、耐腐蚀性能优异，焊接可靠性高，延长产品使用寿命。

9. 金属化孔工艺成熟，孔壁镀铜均匀，导通性能优异，层间信号传输稳定，降低功率损耗。

10. 严格控制机械加工精度，定位孔精准，装配公差小，保障与其他部件的精准适配安装。

11. 工业级环境适应性强，具备良好的抗潮湿、抗振动性能，可在-25℃至+70℃恶劣工况下稳定运行。

12. 兼容自动化贴片与焊接工艺，可实现大批量标准化生产，保障产品一致性与生产效率。

13. 预留充足的测试点与调试接口，便于生产检测与后期故障排查，降低运维成本。

14. 符合RoHS环保标准，采用无卤环保材料与工艺，满足绿色生产与应用要求。

15. 广泛应用于工业控制设备、智能测控系统、自动化生产线等领域，为核心部件提供稳定可靠供电。

3123634-1电源板 英文资料：

3123634-1 Power Board Product Features

1. Using high-quality FR-4 substrate with a glass transition temperature (Tg) ≥ 150 ℃, it has excellent high temperature resistance and mechanical stability, and is suitable for industrial power supply high-temperature working environment.

2. Equipped with an efficient DC-DC conversion circuit, the conversion efficiency is over 95%, with low energy consumption and no need for additional fan cooling, resulting in significant energy-saving effects.

3. Supports wide voltage input design, suitable for 8-32Vdc wide input, strong resistance to voltage fluctuations, and can adapt to various industrial power systems.

4. Equipped with multiple precise output functions, it can stably provide various voltages such as 5V, 12V, 24V, etc., to meet the power supply needs of different loads.

5. Adopting independent power and ground layer wiring design, combined with impedance control technology, effectively reduces signal crosstalk and electromagnetic interference, and ensures power supply stability.

6. Integrate multiple protection mechanisms for overcurrent, overvoltage, undervoltage, and short circuit, quickly respond to power outages in case of faults, and comprehensively protect the safety of backend equipment.

7. Equipped with over temperature protection function, built-in temperature sensor, automatically triggers protection in case of abnormal temperature, avoiding device damage due to overheating.

8. Adopting chemical immersion gold surface treatment process, the contact has excellent oxidation resistance and corrosion resistance, high welding reliability, and extends product service life.

9. The metalized hole process is mature, with uniform copper plating on the hole wall, excellent conductivity, stable interlayer signal transmission, and reduced power loss.

10. Strictly control the machining accuracy, precise positioning holes, small assembly tolerances, and ensure accurate fitting and installation with other components.

11. Industrial grade environment has strong adaptability, good resistance to moisture and vibration, and can operate stably under harsh conditions from -25 ℃ to+70 ℃.

12. Compatible with automated SMT and soldering processes, it can achieve large-scale standardized production, ensuring product consistency and production efficiency.

13. Reserve sufficient testing points and debugging interfaces for production testing and later troubleshooting, reducing operation and maintenance costs.

14. Compliant with RoHS environmental standards, using halogen-free environmentally friendly materials and processes to meet green production and application requirements.

Widely used in industrial control equipment, intelligent measurement and control systems, automated production lines and other fields, providing stable and reliable power supply for core components.
