1.产 品 资 料 介 绍：

PAAE065993中继卡产品特点

1. 专为瓦锡兰船舶调速系统设计，作为C3调谐中继卡，实现信号精准中转与适配；

2. 具备RS-485/422总线中继功能，可放大衰减信号，延长通信距离至1200米，保障远距离传输稳定；

3. 内置光电隔离模块，提供3000V隔离电压，有效抑制共模干扰与地电势差影响；

4. 支持数据流向自动识别与切换，零延时传输设计，无需手动配置软硬件，即插即用；

5. 配备600W雷击浪涌保护与15KV静电防护，抵御船舶复杂环境中的电磁冲击；

6. 工作温度覆盖-20℃~+60℃，适配船舶机舱高低温、高湿度恶劣工况；

7. 采用全金属外壳封装，防静电、抗振动性能优异，符合海事设备机械强度标准；

8. 适配24VDC船舶专用电源，电压波动适应性强，可直接接入船舶供电系统；

9. 支持总线拓扑结构转换，可将总线型转为T型拓扑，方便船舶现场布线施工；

10. 兼容Modbus-RTU工业协议，无缝对接船舶PLC及中控系统，实现数据实时同步；

11. 具备故障自诊断功能，异常状态及时反馈至中控，便于船舶设备快速运维；

12. 采用标准化引脚定义，与瓦锡兰系列控制模块完美兼容，替换升级便捷；

13. 支持多节点扩展，单卡可增加总线负载设备数量，满足船舶多设备组网需求；

14. 通过海事设备专用认证，符合船舶行业安全与电磁兼容规范；

15. 广泛应用于瓦锡兰柴油机测速系统、船舶动力控制单元等海事自动化场景。

PAAE065993中继卡 英文资料：

PAAE065993 Relay Card Product Features

1. Designed specifically for the speed control system of W ä rtsil ä ships, serving as a C3 tuning relay card to achieve precise signal transfer and adaptation;

2. Equipped with RS-485/422 bus relay function, it can amplify attenuated signals, extend communication distance to 1200 meters, and ensure stable long-distance transmission;

3. Built in photoelectric isolation module, providing 3000V isolation voltage, effectively suppressing common mode interference and ground potential difference effects;

4. Support automatic recognition and switching of data flow direction, zero latency transmission design, no need to manually configure software and hardware, plug and play;

5. Equipped with 600W lightning surge protection and 15KV electrostatic protection to resist electromagnetic impact in complex ship environments;

6. The working temperature covers -20 ℃~+60 ℃, suitable for harsh working conditions such as high and low temperature, high humidity in ship engine rooms;

7. Adopting a fully metal shell packaging, it has excellent anti-static and anti vibration performance, and meets the mechanical strength standards of maritime equipment;

8. Suitable for 24VDC ship specific power supply, with strong adaptability to voltage fluctuations, and can be directly connected to the ship power supply system;

9. Support bus topology conversion, which can convert bus type to T-shaped topology, facilitating on-site wiring construction of ships;

10. Compatible with Modbus RTU industrial protocol, seamlessly integrated with ship PLC and central control system, achieving real-time data synchronization;

11. Equipped with fault self diagnosis function, timely feedback of abnormal status to the central control, facilitating rapid operation and maintenance of ship equipment;

12. Adopting standardized pin definitions, it is perfectly compatible with W ä rtsil ä series control modules and easy to ｒｅｐｌａｃｅ and upgrade;

13. Support multi node expansion, single card can increase the number of bus load devices, meeting the networking needs of multiple devices on ships;

14. Passed specialized certification for maritime equipment, in compliance with safety and electromagnetic compatibility regulations in the shipbuilding industry;

15. Widely used in maritime automation scenarios such as Wartsila diesel engine speed measurement systems and ship power control units.

PAAE065993中继卡 产品展示

产品视频
