1.产 品 资 料 介 绍：

10AX057K4F40I3产品应用领域

注：10AX057K4F40I3并非控制器模块，而是Intel Arria® 10系列FPGA芯片（20nm制程，FBGA1517封装）。其兼具高性能、低功耗及高速传输能力，集成丰富硬IP与可编程资源，适配中高端严苛场景，核心应用领域如下：

一、通信领域

作为Arria® 10系列的核心应用领域，10AX057K4F40I3凭借高速数据处理与传输能力，成为通信系统的关键核心器件，细分场景包括：

- 无线通信：适用于5G基站的远端射频头（RRH）信道卡、交换卡，以及移动回传系统，可实现高速信号的调制解调、数据转发与带宽聚合，保障5G通信的低延迟与高带宽需求；

无线通信：5G基站RRH信道卡、移动回传系统，保障低延迟高带宽；

- 有线通信：适配40G/100G光通信设备中的复用器、转发器，以及100G线路卡，可完成高速光信号的接收、处理与转发，同时支持桥接、聚合等功能，是骨干网、数据中心互联的核心组件。

有线通信：40G/100G光通信设备，支撑骨干网、数据中心互联。

二、广播与音视频领域

依托高并行处理能力，适配音视频实时处理需求，应用于：

专业广播：演播室交换机、音视频传输服务器，保障高清稳定传输；

高端音视频交互：视频会议系统，降低延迟提升体验。

三、计算与存储领域

为计算与存储系统提供性能加速，具体应用：

数据中心/云计算：云服务器加速卡，提升算力密集型任务效率；

存储加速：闪存缓存系统，提升IO性能减少访问延迟。

四、医疗设备领域

凭借高精度信号处理能力，适配医疗设备高要求，应用于：

诊断成像：MRI、CT扫描仪，提升图像分辨率与诊断准确性；

医疗检测：生化分析仪等，保障检测结果可靠。

五、工业自动化领域

实时逻辑控制与抗干扰性优势显著，应用于工业场景：

PLC核心控制：定制灵活逻辑，适配电机驱动等实时任务；

工业机器人：实现精准运动控制与快速响应。

六、航空航天与国防领域

高可靠性与抗辐射性适配极端环境，应用于：

航空电子：飞机飞行控制、导航系统，保障高空稳定运行；

国防装备：雷达、导弹制导等，支撑国防信息化。

其他场景：高端测试测量设备（信号发生器、示波器）核心模块。

10AX057K4F40I3控制器模块  英文资料：

10AX057K4F40I3 Product Application Fields

Note: 10AX057K4F40I3 is not a controller module, but an Intel Arria ®  10 series FPGA chips (20nm process, FBGA1517 package). It combines high performance, low power consumption, and high-speed transmission capabilities, integrates rich hard IP and programmable resources, adapts to high-end and demanding scenarios, and has the following core application areas:

1、 Communication field

As Arria ®  The core application areas of the 10 series, 10AX057K4F40I3, with its high-speed data processing and transmission capabilities, have become key core components of communication systems. The segmented scenarios include:

-Wireless communication: Suitable for remote radio head (RRH) channel cards, switching cards, and mobile backhaul systems of 5G base stations, it can achieve high-speed signal modulation and demodulation, data forwarding, and bandwidth aggregation, ensuring low latency and high bandwidth requirements for 5G communication;

Wireless communication: 5G base station RRH channel card, mobile backhaul system, ensuring low latency and high bandwidth;

-Wired communication: Suitable for multiplexers, repeaters, and 100G line cards in 40G/100G optical communication equipment, it can complete the reception, processing, and forwarding of high-speed optical signals, while supporting bridging, aggregation, and other functions. It is the core component of backbone networks and data center interconnection.

Wired communication: 40G/100G optical communication equipment, supporting backbone network and data center interconnection.

2、 Broadcasting and audio-visual fields

Relying on high parallel processing capability, suitable for real-time processing requirements of dubbed videos, applied to:

Professional broadcasting: studio switch, audio and video transmission server, ensuring high-definition and stable transmission;

High end audio and video interaction: video conferencing system, reducing latency and improving experience.

3、 In the field of computing and storage

Provide performance acceleration for computing and storage systems, specific applications:

Data center/cloud computing: Cloud server acceleration card to improve the efficiency of computationally intensive tasks;

Storage acceleration: Flash caching system improves IO performance and reduces access latency.

4、 Medical equipment field

With high-precision signal processing capabilities, it adapts to the high requirements of medical equipment and is applied to:

Diagnostic imaging: MRI and CT scanners to improve image resolution and diagnostic accuracy;

Medical testing: Biochemical analyzers, etc., ensure reliable testing results.

5、 Industrial automation field

Real time logic control and anti-interference advantages are significant, applied in industrial scenarios:

PLC core control: Customize flexible logic, adapt to real-time tasks such as motor drives;

Industrial robots: achieving precise motion control and rapid response.

6、 Aerospace and Defense Fields

High reliability and radiation resistance suitable for extreme environments, applied to:

Avionics: Aircraft flight control, navigation system, ensuring stable high-altitude operation;

National defense equipment: radar, missile guidance, etc., supporting national defense informatization.

Other scenarios: Core modules of high-end testing and measurement equipment (signal generators, oscilloscopes).

10AX057K4F40I3控制器模块  产品展示
