KM1-PMU2A-FLK电源监控器

KM1-PMU2A-FLK电源监控器

1.产 品 资 料 介 绍：

KM1-PMU2A-FLK电源监控器产品特点

1. 采用24位高精度电力采样芯片，测量精度达±0.2%FS，精准监测电压、电流、功率等多类电参量；

2. 支持交流/直流电源双模式监测，适配不同配电场景，可灵活切换测量量程与模式；

3. 具备实时告警功能，针对过压、过流、欠压、过热等异常状态快速触发告警，保障供电安全；

4. 内置数据记录功能，自动存储历史告警与电参量曲线，便于故障追溯与电能分析；

5. 配备RS485通讯接口，兼容Modbus-RTU协议，可无缝对接PLC、DCS及电力监控系统；

6. 适配8~30VDC宽压供电，具备电源反接保护，可直接接入工业现场供电系统，运行稳定；

7. 工作温度覆盖-20℃~70℃，耐受高湿度、多粉尘工业环境，适配复杂配电工况；

8. 配备高亮LED状态指示灯，直观显示电源运行、通讯及告警状态，运维排查更便捷；

9. 输入与通讯回路采用1500VAC电气隔离设计，有效抵御电磁干扰，保障信号传输稳定；

10. 支持电能统计报表生成，可查询任意时间段用电数据，助力能耗管控与节能优化；

11. 采用35mm DIN导轨安装设计，结构紧凑，安装拆卸便捷，节省配电柜体空间；

12. 具备分级权限管理功能，限制参数修改操作，防止误操作影响监控系统正常运行；

13. 支持WEB远程访问与参数配置，可实时查看监控数据，简化远程运维流程；

14. 符合DL/T721-2013配网自动化标准，通过EMC电磁兼容认证，适配工业配电规范；

15. 广泛应用于35kV及以下供配电系统、自动化生产线、数据中心等场景的电源状态监控。

KM1-PMU2A-FLK电源监控器 英文资料：

Product Features of KM1-PMU2A-FLK Power Monitor

1. Using a 24 bit high-precision power sampling chip, the measurement accuracy reaches ± 0.2% FS, accurately monitoring multiple types of electrical parameters such as voltage, current, and power;

2. Supports dual-mode monitoring of AC/DC power supply, adapts to different distribution scenarios, and can flexibly switch measurement range and mode;

3. Equipped with real-time alarm function, it can quickly trigger alarms for abnormal states such as overvoltage, overcurrent, undervoltage, and overheating, ensuring power supply safety;

4. Built in data recording function, automatically storing historical alarms and electrical parameter curves for easy fault tracing and energy analysis;

5. Equipped with RS485 communication interface, compatible with Modbus RTU protocol, can seamlessly integrate with PLC, DCS and power monitoring systems;

6. Suitable for 8-30VDC wide voltage power supply, with power reverse protection, can be directly connected to industrial site power supply system, and runs stably;

7. The working temperature ranges from -20 ℃ to 70 ℃, and it can withstand high humidity and dusty industrial environments, adapting to complex power distribution conditions;

8. Equipped with high brightness LED status indicator lights, it intuitively displays the power operation, communication, and alarm status, making maintenance and troubleshooting more convenient;

9. The input and communication circuits are designed with 1500VAC electrical isolation to effectively resist electromagnetic interference and ensure stable signal transmission;

10. Support the generation of electricity statistics reports, which can query electricity consumption data at any time period, helping with energy consumption control and energy-saving optimization;

11. Adopting a 35mm DIN rail installation design, the structure is compact, easy to install and disassemble, and saves space in the distribution cabinet;

12. It has a hierarchical permission management function, which restricts parameter modification operations and prevents accidental operations from affecting the normal operation of the monitoring system;

13. Support WEB remote access and parameter configuration, allowing real-time viewing of monitoring data and simplifying remote operation and maintenance processes;

14. Complies with DL/T721-2013 distribution automation standards, has passed EMC electromagnetic compatibility certification, and is compatible with industrial distribution specifications;

15. Widely used for power status monitoring in 35kV and below power supply and distribution systems, automated production lines, data centers, and other scenarios.

KM1-PMU2A-FLK电源监控器 产品展示

产品视频
