1.产 品 资 料 介 绍：
PCI-6220数据采集卡产品特点（15条）
PCI-6220为NI M系列多功能DAQ采集卡，基于PCI 2.2总线设计，适配工业自动化、科研实验等场景，核心特点如下：
1. 多通道模拟输入
支持16路单端/8路差分模拟输入，可灵活适配不同传感器，满足多参数采集需求。
2. 16位高精度AD转换
搭载16位ADC转换器，结合NI-MCal校准技术，最小电压范围敏感度低至5.2μV，测量精度优异。
3. 高速可编程采样
单通道最高采样率达250 kS/s，采样速率可按需编程调节，精准捕捉瞬态信号。
4. 多量程电压适配
提供±10V、±5V等4种可选电压范围，最小支持±200mV量程，适配不同幅值信号。
5. 板载缓存防丢数
配备4095样本板载FIFO缓存，支持DMA缓冲操作，保障连续采集时数据传输稳定。
6. 24路双向数字I/O
集成24路TTL/CMOS电平数字通道，支持可编程上电状态，满足开关量控制与监测。
7. 双路32位计数器
内置2个32位通用计数器，支持频率测量、脉冲生成、编码器输入，时基稳定度达50 ppm。
8. 丰富触发定时模式
支持软件、外部、数字多种触发方式，配备1 MHz时钟速率，实现事件驱动采集。
9. 强化抗干扰设计
采用屏蔽与滤波技术，输入阻抗＞1 GΩ，有效抵御工业电磁干扰，保障复杂环境稳定运行。
10. 宽温环境适配
工作温度0℃至55℃，存储温度-20℃至85℃，适配各类工业与实验室场景。
11. 多系统软件兼容
支持Windows、Linux、Mac OS及实时系统，兼容LabVIEW、MATLAB、C/C++等开发环境。
12. 标准PCI接口安装
采用32位5V PCI 2.2接口，通过68针VHDCI母头连接，插卡式安装适配主流工控机。
13. 丰富信号调理选项
支持70余种信号调理配件，可优化不同传感器信号，拓展适用范围与测量精度。
14. 符合RoHS合规标准
满足RoHS指令要求，环保性达标，适配合规性严格的工业与科研场景。
15. 便捷数据处理
附带LabVIEW SignalExpress软件，无需编程即可快速完成数据采集、分析与显示。
PCI-6220数据采集卡 英文资料：
PCI-6220 Data Acquisition Card Product Features (15)
PCI-6220 is a NI M series multifunctional DAQ acquisition card designed based on PCI 2.2 bus, suitable for industrial automation, scientific research experiments and other scenarios. Its core features are as follows:
1. Multi channel analog input
It supports 16 channels of single ended/8 channels of differential analog input, and can flexibly adapt to different sensors to meet the requirements of multi parameter acquisition.
2. 16 bit high-precision AD conversion
Equipped with a 16 bit ADC converter and combined with NI MCal calibration technology, the minimum voltage range sensitivity is as low as 5.2 μ V, and the measurement accuracy is excellent.
3. High speed programmable sampling
The maximum sampling rate for a single channel is 250 kS/s, and the sampling rate can be programmed and adjusted as needed to accurately capture transient signals.
4. Multi range voltage adaptation
Provide four optional voltage ranges, including ± 10V and ± 5V, with a minimum support of ± 200mV range, suitable for different amplitude signals.
5. Number of onboard cache anti loss measures
Equipped with 4095 sample board FIFO buffer, supporting DMA buffer operation, ensuring stable data transmission during continuous acquisition.
6. 24 bidirectional digital I/O channels
Integrate 24 TTL/CMOS level digital channels, support programmable power on status, and meet switch control and monitoring requirements.
7. Dual channel 32-bit counter
Built in 2 32-bit universal counters, supporting frequency measurement, pulse generation, encoder input, and a time base stability of 50 ppm.
8. Rich triggering timing modes
Supports multiple triggering methods including software, external, and digital, equipped with a 1 MHz clock rate to achieve event driven data acquisition.
9. Strengthen anti-interference design
By using shielding and filtering techniques, the input impedance is greater than 1 G Ω, effectively resisting industrial electromagnetic interference and ensuring stable operation in complex environments.
10. Wide temperature environment adaptation
Working temperature range from 0 ℃ to 55 ℃, storage temperature range from -20 ℃ to 85 ℃, suitable for various industrial and laboratory scenarios.
11. Multi system software compatibility
Supports Windows, Linux, Mac OS, and real-time systems, compatible with development environments such as LabVIEW, MATLAB, C/C++, etc.
12. Installation of standard PCI interface
Adopting a 32-bit 5V PCI 2.2 interface, connected through a 68 pin VHDCI female connector, and installed in a plug-in manner to adapt to mainstream industrial control computers.
13. Rich signal conditioning options
It supports more than 70 kinds of signal conditioning accessories, which can optimize different sensor signals and expand the scope of application and measurement accuracy.
14. Compliant with RoHS compliance standards
Meets RoHS directive requirements, meets environmental standards, and is suitable for industrial and scientific research scenarios with strict regulations.
15. Convenient data processing
Equipped with LabVIEW SignalExpress software, data acquisition, analysis, and display can be quickly completed without programming.
