1.产 品 资 料 介 绍：

L5504D2A电源模块产品特点（10条）

L5504D2A是奇胜（Clipsal）C-BUS2系列工业级电源继电器模块，集成4通道无电压继电器与调光功能，专为楼宇自控、工业自动化及智能配电场景设计，适配220-240V工频供电，核心特点如下：

1. 4通道独立控制

内置4路独立无电压继电器，每通道额定负载2A，支持单独开关控制与调光调节，可分别驱动灯光、小型执行器等负载，适配多回路精准控制需求。

2. 宽幅工频电压适配

支持220-240VAC宽幅输入，兼容50/60Hz工频，电压波动容忍度±10%，无需额外调压即可适配全球多数地区市电标准，运行稳定可靠。

3. 集成调光控制功能

自带专业调光模块，支持平滑调光与场景切换，调光范围0-100%连续可调，适配白炽灯、LED等多种光源，满足智能照明及节能控制需求。

4. C-BUS2总线兼容

原生兼容C-BUS2智能总线协议，可无缝接入楼宇自控系统，实现远程控制、参数配置与多模块联动，支持与其他C-BUS设备组网扩展。

5. 多重安全防护设计

内置过流、过载及浪涌保护电路，继电器触点采用耐电弧材质，电气寿命≥10万次，有效防护模块自身及后端负载安全，故障时自动切断回路。

6. 工业级抗干扰性能

采用电磁屏蔽与滤波设计，具备良好抗电磁辐射与电源干扰能力，可在工业车间、楼宇配电房等复杂电磁环境中稳定工作，信号传输无延迟。

7. 便捷安装与维护

适配35mm标准DIN导轨安装，体积紧凑节省机柜空间，接线端子采用按压式设计，接线牢固且拆装便捷，支持热插拔维护，提升运维效率。

8. 直观状态监测指示

前面板配备电源、通道工作状态及故障告警LED指示灯，每通道状态独立显示，可快速识别运行异常，缩短故障排查时间。

9. 宽温环境耐受

工作温度范围0℃~+40℃，存储温度-20℃~+60℃，耐受95%湿度（无凝露），适配室内楼宇、工业厂房等多数场景的温湿度环境。

10. 国际合规认证保障

通过CE、UL等国际安规认证，遵循无铅环保标准，符合工业级电源模块制造规范与楼宇自控系统可靠性要求，适配全球多地区应用场景。

L5504D2A电源模块 英文资料：

L5504D2A power module product features (10 items)

L5504D2A is a Clipsal C-BUS2 series industrial grade power relay module that integrates 4-channel voltage free relays and dimming functions. It is designed specifically for building automation, industrial automation, and intelligent power distribution scenarios, and is compatible with 220-240V power supply. Its core features are as follows:

1. 4-channel independent control

Equipped with 4 independent voltage free relays, each channel has a rated load of 2A and supports separate switch control and dimming adjustment. It can drive loads such as lights and small actuators separately, adapting to the precise control needs of multiple circuits.

2. Wide frequency voltage adaptation

Supports 220-240VAC wide input, compatible with 50/60Hz power frequency, with a voltage fluctuation tolerance of ± 10%, and can adapt to most global power standards without additional voltage regulation, ensuring stable and reliable operation.

3. Integrated dimming control function

Equipped with a professional dimming module, it supports smooth dimming and scene switching, with a continuously adjustable dimming range of 0-100%. It is compatible with various light sources such as incandescent lamps and LEDs, meeting the needs of intelligent lighting and energy-saving control.

4. C-BUS2 bus compatibility

Native compatible with the C-BUS2 intelligent bus protocol, it can seamlessly integrate into building automation systems, achieve remote control, parameter configuration, and multi module linkage, and support network expansion with other C-BUS devices.

5. Multiple security protection design

Built in overcurrent, overload, and surge protection circuits, relay contacts made of arc resistant materials, with an electrical lifespan of ≥ 100000 times, effectively protecting the module itself and the backend load safety, and automatically cutting off the circuit in case of faults.

6. Industrial grade anti-interference performance

Adopting electromagnetic shielding and filtering design, it has good resistance to electromagnetic radiation and power interference, and can work stably in complex electromagnetic environments such as industrial workshops and building distribution rooms, with no delay in signal transmission.

7. Convenient installation and maintenance

Suitable for 35mm standard DIN rail installation, compact in size and saves cabinet space. The terminal block adopts a press design, which is firm in wiring and easy to disassemble. It supports hot swappable maintenance and improves operation and maintenance efficiency.

8. Intuitive state monitoring indication

The front panel is equipped with LED indicators for power supply, channel working status, and fault alarm. Each channel status is independently displayed, which can quickly identify abnormal operation and shorten the troubleshooting time.

9. Wide temperature environment tolerance

The working temperature range is 0 ℃~+40 ℃, the storage temperature is -20 ℃~+60 ℃, and it can withstand 95% humidity (without condensation). It is suitable for the temperature and humidity environment of most indoor buildings, industrial plants, and other scenarios.

10. International compliance certification guarantee

Through international safety certifications such as CE and UL, following lead-free environmental standards, complying with industrial grade power module manufacturing specifications and building automation system reliability requirements, and adapting to application scenarios in multiple regions around the world.

L5504D2A电源模块 产品展示

产品视频
