ST-10M1定时器

ST-10M1定时器

1.产 品 资 料 介 绍：

ST-10M1定时器产品特点（10条）

ST-10M1是一款工业级高精度数字式定时器，采用10ms级精准计时核心，集成多模式定时与可靠输出功能，专为化工、电力、自动化生产线及楼宇自控等场景设计，适配多回路时序控制需求，核心特点如下：

1. 10ms级高精度计时

采用高精度计时芯片，最小计时精度达10ms，定时范围可在0.01秒至999分钟内连续可调，误差率≤±0.1%，满足高精准时序控制场景需求。

2. 多模式定时功能

支持通电延时（TON）、断电延时（TOF）、脉冲输出（TP）三种核心模式，可通过面板按键切换，适配单回路延时控制、循环触发等多样化时序需求。

3. 宽幅电压适配供电

支持85-264VAC宽范围交流输入，兼容50/60Hz工频，电压波动容忍度±15%，无需额外调压即可适配全球多数地区市电及工业电源标准，运行稳定。

4. 可靠触点输出设计

配置1组转换型触点，额定负载5A@250VAC，触点采用耐电弧抗氧化材质，电气寿命≥10万次，可直接驱动电磁阀、接触器等工业负载，切换可靠无卡顿。

5. 断电参数记忆功能

内置长效EEPROM存储芯片，断电后定时参数可永久保存，数据保持时间长达10年，复电后自动恢复之前设定，无需重新配置，提升运维效率。

6. 工业级抗干扰性能

采用电磁屏蔽与RC滤波双重设计，具备抗静电、抗电快速瞬变脉冲群能力，符合IEC61000-4系列抗干扰标准，可在变频器周边等强干扰环境稳定工作。

7. 直观数显与操作

配备高亮度LED数码管，同步显示设定时间与剩余时间，面板采用防水按键设计，操作便捷且不易误触，支持一键复位与模式切换，调试简单高效。

8. 多重安全防护

内置过流、短路及反极性保护电路，外壳采用阻燃ABS材质，燃烧等级达94V-0级，有效防护模块自身及后端负载安全，避免故障扩大。

9. 宽温环境耐受

工作温度范围-25℃~+70℃，存储温度-40℃~+85℃，耐受95%湿度（无凝露），适配户外、工业厂房等复杂温湿度工况，稳定性优异。

10. 便捷安装与适配

适配35mm标准DIN导轨安装，体积紧凑节省机柜空间，接线端子采用按压式设计，牢固不易松动，可无缝融入现有工业自控系统，适配多场景部署。

ST-10M1定时器 英文资料：

ST-10M1 Timer Product Features (10)

ST-10M1 is an industrial grade high-precision digital timer that uses a 10ms level precision timing core and integrates multi-mode timing and reliable output functions. It is designed for scenarios such as chemical, power, automation production lines, and building automation, and is suitable for multi loop timing control requirements. The core features are as follows:

1. 10ms high-precision timing

Using high-precision timing chips, the minimum timing accuracy reaches 10ms, and the timing range can be continuously adjusted from 0.01 seconds to 999 minutes with an error rate of ≤± 0.1%, meeting the requirements of high-precision timing control scenarios.

2. Multi mode timing function

Supports three core modes: power on delay (TON), power off delay (TOF), and pulse output (TP), which can be switched through panel buttons and adapted to diverse timing requirements such as single loop delay control and loop triggering.

3. Wide voltage adaptation power supply

Supports 85-264VAC wide range AC input, compatible with 50/60Hz power frequency, with a voltage fluctuation tolerance of ± 15%, and can adapt to most global power and industrial power standards without additional voltage regulation, ensuring stable operation.

4. Reliable contact output design

Configure 1 set of conversion type contacts, rated load 5A@250VAC The contacts are made of arc resistant and anti-oxidation materials, with an electrical life of ≥ 100000 times. They can directly drive industrial loads such as solenoid valves and contactors, and switch reliably without jamming.

5. Power off parameter memory function

Built in long-lasting EEPROM storage chip, timing parameters can be permanently saved after power failure, with data retention time of up to 10 years. After power restoration, it automatically restores the previous settings without the need for reconfiguration, improving operation and maintenance efficiency.

6. Industrial grade anti-interference performance

Adopting a dual design of electromagnetic shielding and RC filtering, it has the ability to resist static electricity and fast transient pulse trains, complies with the IEC61000-4 series anti-interference standards, and can work stably in strong interference environments such as around the frequency converter.

7. Intuitive digital display and operation

Equipped with a high brightness LED digital tube, it synchronously displays the set time and remaining time. The panel adopts a waterproof button design, which is easy to operate and not easily touched by mistake. It supports one click reset and mode switching, and debugging is simple and efficient.

8. Multiple security protections

Built in overcurrent, short circuit, and reverse polarity protection circuits, the shell is made of flame-retardant ABS material, with a combustion level of 94V-0, effectively protecting the module itself and the backend load safety, and avoiding the expansion of faults.

9. Wide temperature environment tolerance

The working temperature range is -25 ℃~+70 ℃, the storage temperature is -40 ℃~+85 ℃, and it can withstand 95% humidity (without condensation). It is suitable for complex temperature and humidity conditions such as outdoor and industrial plants, and has excellent stability.

10. Convenient installation and adaptation

Compatible with 35mm standard DIN rail installation, compact in size and saves cabinet space. The wiring terminals adopt a press type design, which is firm and not easy to loosen, and can seamlessly integrate into existing industrial automation systems, suitable for multi scenario deployment.

ST-10M1定时器 产品展示
