244-INWW数字仪表计量系统

244-INWW数字仪表计量系统

1.产 品 资 料 介 绍：

244-INWW数字仪表计量系统产品特点（10条）

244-INWW是一款工业级一体化数字仪表计量系统，集成多参数采集、精准计量、数据联传及智能管控功能，专为电力、化工、液态烃充装等场景设计，适配从现场检测到后台结算的全流程计量需求，核心特点如下：

1. 多参数精准计量

支持流量、压力、温度、密度多参数同步采集，计量精度达±0.1%FS，无需额外补偿模块即可实现标方计量，有效降低供销差，保障计量公平性与准确性。

2. 全流程数据闭环管控

构建“现场检测-数据传输-后台分析-结算归档”闭环体系，可与MES、ERP系统无缝对接，实现计量数据自动上传、业务结算智能化，减少人工录入误差。

3. 多协议兼容通讯

原生支持Modbus-RTU、Profinet及以太网通讯协议，可与DCS系统、智能仪表、批量控制器联动，实现远程监控、参数配置与指令下达，适配分布式控制架构。

4. 多重安全联锁保护

集成防静电接地、超压超流、液位开关等安全联锁功能，异常工况下自动停止计量并触发告警，同时记录故障信息，保障现场作业安全，避免事故扩大。

5. 智能报表与数据追溯

自动生成班、日、月统计报表，支持按物料、时间、工位等条件筛选查询，历史数据存储容量达100万条以上，数据可追溯周期超3年，满足合规审计需求。

6. 权限分级与操作留痕

采用三级权限管理机制（管理员、操作员、观察员），所有关键操作需口令验证，操作记录自动存盘且不可篡改，便于责任追溯与流程管控。

7. 直观可视化操作界面

配备高清彩色触摸屏，实时显示瞬时量、累计量、工况参数及告警信息，支持一键启停、参数校准与模式切换，操作简洁易懂，调试维护高效。

8. 工业级环境适应性

控制单元防护等级达IP65，工作温度范围-20℃~+60℃，耐受95%湿度（可凝露），具备强抗电磁干扰能力，适配户外、化工车间等复杂工况。

9. 模块化扩展设计

采用模块化架构，支持计量通道、通讯接口、扩展模块按需增减，可灵活适配单工位独立计量与多工位集中管控场景，满足系统升级与扩容需求。

10. 合规认证与标准化适配

符合国家计量检定标准及IEC工业规范，通过CE、UL安规认证，支持二维码“一码通”全流程管控，可无缝融入现有工业自动化体系，适配全球多地区应用。

244-INWW数字仪表计量系统 英文资料：

244-INWW digital instrument measurement system product features (10 points)

244-INWW is an industrial grade integrated digital instrument measurement system that integrates multi parameter acquisition, precise measurement, data transmission, and intelligent control functions. It is designed for scenarios such as power, chemical, and liquid hydrocarbon filling, and is suitable for the full process measurement needs from on-site detection to backend settlement. Its core features are as follows:

1. Multi parameter precise measurement

Support synchronous acquisition of multiple parameters including flow rate, pressure, temperature, and density, with a measurement accuracy of ± 0.1% FS. Standard measurement can be achieved without the need for additional compensation modules, effectively reducing supply and sales differences and ensuring measurement fairness and accuracy.

2. Full process data closed-loop control

Build a closed-loop system of "on-site inspection data transmission backend analysis settlement archiving", which can seamlessly integrate with MES and ERP systems, achieve automatic uploading of measurement data, intelligent business settlement, and reduce manual input errors.

3. Multi protocol compatible communication

Native support for Modbus RTU, Profinet, and Ethernet communication protocols, can be linked with DCS systems, intelligent instruments, and batch controllers to achieve remote monitoring, parameter configuration, and command issuance, and is compatible with distributed control architectures.

4. Multiple safety interlock protection

Integrated safety interlock functions such as anti-static grounding, overpressure and overcurrent, liquid level switch, etc., automatically stop measuring and trigger alarms under abnormal working conditions, while recording fault information to ensure on-site operation safety and avoid the expansion of accidents.

5. Intelligent reporting and data traceability

Automatically generate class, daily, and monthly statistical reports, support filtering and querying by material, time, workstation, and other conditions, with a historical data storage capacity of over 1 million records and a data traceability period of over 3 years, meeting compliance audit requirements.

6. Permission grading and operation tracking

Adopting a three-level permission management mechanism (administrator, operator, observer), all key operations require password verification, and operation records are automatically saved and cannot be tampered with, facilitating responsibility tracing and process control.

7. Intuitive and visual operation interface

Equipped with high-definition color touch screen, real-time display of instantaneous quantity, cumulative quantity, working condition parameters and alarm information, supporting one click start stop, parameter calibration and mode switching, simple and easy to understand operation, efficient debugging and maintenance.

8. Industrial grade environmental adaptability

The protection level of the control unit reaches IP65, the working temperature range is -20 ℃~+60 ℃, it can withstand 95% humidity (can condense), has strong anti electromagnetic interference ability, and is suitable for complex working conditions such as outdoor and chemical workshops.

9. Modular Expansion Design

Adopting a modular architecture, it supports adding or removing measurement channels, communication interfaces, and expansion modules as needed, and can flexibly adapt to single station independent measurement and multi station centralized control scenarios, meeting system upgrade and expansion needs.

10. Compliance certification and standardization adaptation

Complies with national metrological verification standards and IEC industrial specifications, has passed CE and UL safety certification, supports full process control of QR code "one code pass", can seamlessly integrate into existing industrial automation systems, and is suitable for applications in multiple regions around the world.

244-INWW数字仪表计量系统 产品展示

产品视频
